MRM Elgin Filler Liquid Grav/Press IFL SERIES

  Back to All Equipment

MRM Elgin, Model, IFL Series, 12-head, inline, intermittent motion, stainless steel, gravity overflow filler rated from 12 to 72 containers per minute – depending on materials, application and machine configuration. Fill Volume: Fill to level. Container size up to 7" in Diameter. Equipped with 120" long x 3-1/4" wide plastic Delran belt conveyor with adjustable guide rails, 12 filling heads with 5/8" OD nozzleson 56" long slide bar, no container / no fill, product and overflow tanks with float valve and centrifugal pump. Control panel with filler, conveyor and pump on / off switches.

OAD: 134" L x 44" W x 78" H
