Urschel Laboratories Inc Cutter, Slicer SPRINT

• Manufacturer: Urschel
• Model: SPRINT
• Category: Cutter Slicer

Urschel, Model SPRINT, Stainless steel cutter, uniformly dices, strip cuts and slices a wide variety of products at high production rated with pounds of product per hour – depending on materials and application. Accepts products up to 6½" in any dimension. Equipped with 16" long x 12" wide x 20" deep product feed hopper, (4) paddle impeller, slicing and slitting knife stations with cross cut station. 20" long x 9" wide product discharge with 32" floor clearence. Control panel has start, stop e-stop controls. Mounted on (4) stainless steel legs with casters.

Types of cuts and slices:

Flat slices:1/16 to 1"
Crinkle Slices: 1/8" to 1"
Deep Crinkle Slices: 1/8" to 1/2"

Strip cuts:
Flat Strip Minimum / Maximum 1/8 x 1/8" to 1 x 1" x length of product.
Crinkle strips 9/32 x 9/32" length of product
Circular knife cuts: 1/8 to 3"
Crosscut knife cuts: 1/8 to 1-1/2"
Crosscut knife crinkle cuts: 9/32 to 5/8"
Crosscut Knife Deep Crinkle Cuts: 3/8 to 1/2"
Crosscut Knife V-Cuts: 5/16 to 1/2"

Shreds: A shredding spindle can be installed in place of the crosscut knife spindle. Shreds will vary depending on number of spacers and shred discs
used.

Change parts required to accommodate size range.

OAD: 55" L x 42" W x 68" H
