Cutter Slicer Machines

Urschel Laboratories Inc Cutter, Slicer Chopper/Processor DIVERSACUT 2110

• Manufacturer: Urschel
• Model Number: DIVERSACUT 2110
• Frain Number: R35270

Urschel Model DIVERSACUT 2110, All stainless steel dicer, uniformly dices, strip cuts and slices a wide variety of products at high production with pounds of product per hour – depending on materials and application. Accepts products up to 10" in any dimension. Equipped with product feed hopper with continuous operation for uninterrupted production and is designed for easy cleanup and maintenance. The crosscut knife spindle in conjunction with the other cutting components creates a compact cutting zone establishing precision cuts as the product moves throughout the process. Commonly used for vegetables, fruits, bakery ingredients, dairy inclusions, meat, poultry, seafood, pet food and alternative plant-based products. Mounted on (4) stainless steel legs.

Types of cuts and slices:

Flat slices:1/16 to 1"
Crinkle Slices: 1/8" to 1"
Deep Crinkle Slices: 1/8" to 1/2"

Strip cuts:
Flat Strip Minimum / Maximum 1/8 x 1/8" to 1 x 1" x length of product.
Crinkle strips 9/32 x 9/32" length of product
Circular knife cuts: 1/8 to 3"
Crosscut knife cuts: 1/8 to 1-1/2"
Crosscut knife crinkle cuts: 9/32 to 5/8"
Crosscut Knife Deep Crinkle Cuts: 3/8 to 1/2"
Crosscut Knife V-Cuts: 5/16 to 1/2"

Shreds: A shredding spindle can be installed in place of the crosscut knife spindle. Shreds will vary depending on number of spacers and shred discs
used.

Change parts required to accommodate size range.

OAD: __" L x __" W x __" H

Urschel Laboratories Inc Cutter, Slicer Slicer OV

• Manufacturer: Urschel
• Model Number: OV
• Frain Number: 5H8905

Urschel, Model OV, automatic stainless steel USDA slicer for uniform crosscut slicing of elongated food products with pounds of product per hour – depending on materials and application. Equipped with 48" long v-belt in feed, 2½" wide product hold down belt and 7" OD discharge with 31" ground clearance. Will accommodate products up to 2¾" OD and capable of flat or crinkle slices and will produce flat slices from 1/16" to 1¾" thick. Change parts are required to accommodate size / cut range. Mounted on (4) stainless steel height adjustable legs.

OAD: 72" L x 30" W x 62" H

Urschel Laboratories Inc Cutter, Slicer Slicer OV

• Manufacturer: Urschel
• Model Number: OV
• Frain Number: 5H4180

Urschel, Model OV, automatic USDA slicer for uniform crosscut slicing of elongated food products. with pounds of product per hour – depending on materials and application. Equipped with 50" long v-belt in feed, 2½" wide product hold down belt and 8" diameter discharge with 25" ground clearance.
Will accommodate products up to 2¾" in diameter, and capable of flat or crinkle slices and will produce flat slices from 1/16" to 1¾" thick. Change parts required to accommodate size / cut range. Mounted on (4) leg stainless steel height adjustable base frame.

OAD: 89" L x 27" W x 54" H

Urschel Laboratories Inc Cutter, Slicer Chopper/Processor OV

• Manufacturer: Urschel
• Model Number: OV
• Frain Number: 5H8070

Urschel, Model OV, automatic, USDA approved slicer, for uniform flat or crinkle style slices of a variety of bakery and snack food products with pounds of product per hour – depending on materials and application. Equipped with 52" long V-Belt in feed with 25" long load area, product hold down belt and 8½" OD discharge with 14" ground clearance. Will accommodate products up to 2¾" in diameter and capable of flat or crinkle slices and will produce flat slices from 1/16" to 1¾" thick. Change parts required to accommodate different size and cut ranges. Mounted on (4) stainless steel legs.

OAD: 73"L x 35"W x 48"H

Urschel Laboratories Inc Cutter, Slicer Chopper/Processor DIVERSACUT2110

• Manufacturer: Urschel
• Model Number: DIVERSACUT2110
• Frain Number: 5H8172

S/S dicer uniformly dices, strip cuts, and slices a wide variety of products at high production capacities and accepts products up to 10" in any dimension. Types of cuts slices: flat & crinkle slices: 1/16 to 1" Strip cuts: flat and crinkle minimum / maximum flat strips 1/8 x 1/8" to 1 x 1" x length of product. Crinkle strips 9/32 x 9/32" length of product.
Circular knife cuts: 1/8 to 3"
Crosscut knife cuts: 1/8 to 1-1/2"
Crosscut knife crinkle cuts: 9/32 to 5/8"
Change parts required to accommodate size range.

OAD: 66"L x 55"W x 75"H

Johnson Industries Internation Cutter, Slicer Slicer 9600

• Manufacturer: Johnson Industries Internation
• Model Number: 9600
• Frain Number: 5H7740

Johnson Industries Model 9600, stainless steel, commercial cheese shredder, used for high-volume shredding and allows you to process up to 40 lb (20 kg) blocks of cheese for size reduction prior to grating at rates up to 10,000 lbs of product per hour – depending on materials, application and operator dexterity. Equipped with 24" long x 8" wide x 12" high dual product chambers with slide open safety covers and (2) pneumatic product pushers, 33" OD and (4) blade cross cut shredding disc with size reduction disc (change part per application} and safety cover. Control panel has A/B panelview controller with auto, hand, off and control power, on / off switches with e-stop. Mounted on stainless steel height adjustable frame and casters.

OAD: 128" L x 40" W x 60" H

Sormac Cutter, Slicer Slicer KP60 / WOS1A

• Manufacturer: Sormac
• Model Number: KP60 / WOS1A
• Frain Number: R33950

Sormac, peeler, topper and segmentor system rated from 75 to 85 pieces per minute – depending on materials, application, machine configuration and operator dexterity. Equipped with Model KP-60 peeler with 40" long V-belt in feed and (8) sets of pressure rollers and peeling plates. Peeler discharges into Model WOS-1A topper / segmentor has 16" wide x 96" long conveyor with flights set on 4" centers, topper / tailer alignment belts, positioning system and static mounted knives. Swing arm controller with push button start / stop, on / off switches and pressure roller adjustment dial. Mounted on stainless steel frames with casters.

OAD: 96"L x 30"W x 56"H (peeler)
108"L x 35"W x 70"H (segmentor)
131"L x 108"W x 70"H (total)

Urschel Laboratories Incorpora Cutter, Slicer Chopper/Processor M

• Manufacturer: Urschel
• Model Number: M
• Frain Number: R31671

Urschel Model M, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and capable of production rates from 500 to 4,500 lbs per hour – depending on materials and application. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 9" load area on feed belt and adjustable feed roll allowing for positive product feed at all thicknesses from 3/8" to 1". Mounted on a stainless steel frame. Change parts required to accommodate different configurations and size ranges.

OAD 106"L x 32"W x 53"H

Urschel Laboratories Inc Cutter, Slicer Slicer CCD

• Manufacturer: Urschel
• Model Number: CCD
• Frain Number: 5H7730

Urschel, Model CCD, stainless steel, slicer, strip cutter, shredder and crinkle cutter used for a variety of different food products with production and volumes rates per hour – depending on materials, application and machine configuration. Flat Slices: 0.8mm to 12.7mm, Standard Crinkle: 3-1/3 to 5.7 waves per inch Depth of Crinkle: 2.0mm to 2.1mm, Thickness: .040mm to .285mm, V-Slices 4.7 to 8 waves per inch Depth of Crinkle: (4.7) 2.1mm, Thickness: 1.0mm to 2.5mm. Depth of Crinkle (8)1.3mm, Thickness: 1.0mm to 2.5mm. Also does Oval, Cresent Shreds and strip cuts (all with proper change parts). Equipped with centrifical type slicer utilizes rotating impeller to force the product to the side walls and thru (8) individual inter-changeable cutting heads that enable the processor to change the type of cuts in minutes and has inexpensive to replace, specially designed throw away knives. Accept products up to 3-1/2" in any dimension. Stainless steel feed hopper, discharge chute and start / stop push buttons controls. Mounted on stainless steel frame with locking casters.

OAD: 55"L x 35"W x 106"H

Urschel Cutter, Slicer Chopper/Processor RAD

• Manufacturer: Urschel
• Model Number: RAD
• Frain Number: 5H7731

Urschel, Model RA-D, All stainless steel, USDA approved, wash-down dicer / strip-cutter capable of production rates from 5,000 to 8,000 lbs per hour -depending on materials and application. capable of handling product up to 3-1/2" in any dimension. Slice thickness ranges from 1/16" to 3/8", circular knives range from 1/8" to 1" and crosscut knives range from 1/8" to 1-1/2" spacing (all with proper change parts). Equipped with top-mounted 15” long x 14” wide x 18” deep stainless steel product feed hopper. Control panel has start, stop and safety controllers. Mounted on stainless steel frame with locking casters. Change parts required to accommodate size ranges.

OAD: 55"L x 35"W x 111"H

Urschel Laboratories Inc Cutter, Slicer Chopper/Processor RAD

• Manufacturer: Urschel
• Model Number: RAD
• Frain Number: 5H7732

Urschel, Model RA-D, All stainless steel, USDA approved, wash-down dicer / strip-cutter capable of production rates from 5,000 to 8,000 lbs per hour -depending on materials and application. capable of handling product up to 3-1/2" in any dimension. Slice thickness ranges from 1/16" to 3/8", circular knives range from 1/8" to 1" and crosscut knives range from 1/8" to 1-1/2" spacing (all with proper change parts). Equipped with top-mounted 15” long x 14” wide x 18” deep stainless steel product feed hopper. Control panel has start, stop and safety controllers. Mounted on stainless steel frame with locking casters. Change parts required to accommodate size ranges.

OAD: 55"L x 35"W x 111"H

Urschel Cutter, Slicer Slicer M

• Manufacturer: Urschel
• Model Number: M
• Frain Number: R32963

Urschel, Model M, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and is capable of production rates from 500 to 4,500 lbs per hour – depending on materials and application. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 8½" load area on feed belt. Mounted on a stainless steel frame with casters. Change parts are needed to accommodate configurations and size range changes.

OAD: 92"L x 35"W x 60"H
