Double Arm Machines

Peerless Mixer Paste Double Arm DA50K-20

• Manufacturer: Peerless
• Model Number: DA50K-20
• Frain Number: 5J5590

Peerless, model DA50K-20, Kleanview open frame, 450 lbs, 79.2 gallon, 304 S/S, jacketed, double arm sigma mixer with amount of product per hour – depending on materials and application. Mixing vessel internal dimensions: 28" long x 36" wide x 33" deep, working capacity of 10.6 ft³ (17.4 ft³ total). Equipped with 12" top mounted pneumatic slide gate product charge port with a 106" infeed height, double sigma mixing blades powered by a 20 hp drive, 120° tilt out with a 36" discharge height powered by a 2 hp hydraulic pack. Control panel with AB PLC and touchscreen HMI.

Top ports:
(1) 5" vent
(2) 2" ID seated bevels

Jacket ports:
(2) 1½" NPT

MAWP: 230 PSI @ 180° F

OAD (Mixer): 91" L x 64" W x 106" H
OAD (cabinet): 74" L x 23" W x 77" H

Baker Perkins / Confectionary Mixer Paste Double Arm 100 GAL

• Manufacturer: Baker Perkins / Confectionary
• Model Number: 100 GAL
• Frain Number: 5G9694

Baker Perkins, jacketed, carbon steel, double arm, sigma style blade mixer with pounds of product per hour – depending on materials and application. Working capacity of 100 gallons (13.3 ft³). Equipped with 34" long x 38" wide x 30" deep, Internal dimensions tilt style mixing chamber, and has top cover with 15" long x 22" wide product port. 34" long x 5" wide double sigma style mixing blades, single end drive 40 Hp motor to chain and sproket drive and 5 hp hydraulic package. Mounted heavy duty base frame.

OAD: 90"L x 78"W x 74"H

Werner & Pfleiderer Mixer Paste Double Arm C/S JKTD TILT

• Manufacturer: Werner & Pfleiderer
• Model Number: C/S JKTD TILT
• Frain Number: 5D7419

33 cu ft carbon steel, jacketed, double arm tilt mixer. Equipped with 2 piece hinged cover, Naben type mixing blades, jacketed body and hollow mixer blades for hot oil, or water cooling supply and (4) 1-1/4" jacket ports. 40 HP double end motor drive, and electrical 3 HP mechanical twin screw tilt motor drive, with guarding for external gears, and is mounted on a carbon steel I-beam base frame.

OAD: 92" L x 82" W x 76" H

Baker Perkins / B P Process Eq Mixer Paste Double Arm

• Manufacturer: Baker Perkins / B P Process Eq
• Model Number:
• Frain Number: 5D7418

Baker Perkins / B & P Process Equipment, 10 cubic foot (80 gallon), carbon steel, double sigma mixer with amount of product per hour – depending on materials and application. Internal mixing chamber dimensions of: (30" in Length x 26" in Width x 26" in Depth. Equipped with full hinged cover and (2) 3 1/2" OD sight glasses, double sigma mixing blades, hydraulic tilt discharge and double end motor drive with jacketed side plates. Control panel has start, stop and e-stop controls. Mounted on heavy duty carbon steel frame.

OAD: 102" L x 72" W x 50" H

Bramley Mixers USA Mixer Paste Double Arm

• Manufacturer: Bramley Mixers USA
• Model Number:
• Frain Number: 5D7417

Bramley Mixers USA Model, 10 cubic foot, stainless steel jacketed, double arm mixer with amount of product per hour – depending on materials and application. Internal mixing chamber dimensions of: 27" in Length x 25" in Width x 24" in Depth and has full jacket rated at 60 psi, with (2) 3/4 threaded ports, powered tilt discharge, safety grating, temperature sensor with LCD, and double end drive.
Mounted on base frame

OAD: 78" L x 48" W x 88" H

J H Day Mixer Paste Double Arm 15

• Manufacturer: J H Day
• Model Number: 15
• Frain Number: 5D7414

15 cubic foot jacketed C/S double sigma blade mixer. Internal mixing chamber dimensions: (38"L x 34"W x 27"D). Equipped with hinged flip top cover, 4" ID product inlet, 18" over lapping sigma blades, (2) 1" threaded jacket inlet/outlets, and a 4 1/2" OD threaded bottom discharge with manual butterfly valve, 3 HP dual end drive, and mounted on a heavy duty cast iron base.

OAD: 81"(L) x 56"(W) x 60"(H)

Mixer Paste Double Arm 9CUFT

• Model Number: 9CUFT
• Frain Number: 5D7413

9 cubic foot C/S, double sigma mixer. Internal mixing chamber dimensions: (29 1/2"L x 27 1/2"W x 21"D). Equipped with counterweighted hinged cover w/ 4" x 4" inlet, single end drive, and mechanical tilt. Mounted on a mild steel frame.

OAD: 82"(L) x 72"(W) x 58"(H)

Baker Perkins / B P Process Eq Mixer Paste Double Arm 10

• Manufacturer: Baker Perkins / B P Process Eq
• Model Number: 10
• Frain Number: 5D7412

100 gallon jacketed, C/S double sigma mixer. Internal mixing chamber dimensions: (26"L x 30"W x 22"Deep). Equipped with hinged flip top cover, hydraulic tilt, and 20 HP Allis Chalmers double end drive. Mounted on a mild steel base.

OAD: 88"(L) x 64"(W) x 58"(H)

Baker Perkins / B P Process Eq Mixer Paste Double Arm 15CUFT

• Manufacturer: Baker Perkins / B P Process Eq
• Model Number: 15CUFT
• Frain Number: 5D7410

Baker Perkins, 15 ft³, dual sigma jacketed mixer. Internal mixing chamber dimensions of 33" long x 38" wide x 30" deep for a working capacity of 75 gallons. Equipped with 5" wide dual sigma blades powered by a 40 Hp drive, hydraulic tilt discharge with a 27" discharge height. Mounted on a painted base frame.

Jacket Fittings:
(7) 3/8" NPT

OAD: 101"L x 78"W x 61"H

J H Day Mixer Paste Double Arm 20CUFT

• Manufacturer: J H Day
• Model Number: 20CUFT
• Frain Number: 5D3219

20 cu. ft. (150 gallon), Double arm, jacketed, sigma mixer with tangential blades. Chamber dimensions: 39"L x 33"W x 30"H. Features a 10" top intake, a hinged cover with a wire screen with 3" x 3" openings and a powered tilt discharge.

OAD: 92"L x 50"W x 80"H

Beken Mixer Paste Double Arm 17GAL

• Manufacturer: Beken
• Model Number: 17GAL
• Frain Number: 5D5131

2 cuft. (17 gal), 304 S/S, jacketed double arm mixer with masticator blades. Inside chamber dimensions: 16" x 16" x 15". Equipped with counterweighted cover, 2" OD threaded center bottom discharge, hydraulic bowl tilt, and 10 HP GE drive motor. Mounted on a heavy duty frame.

OAD: 82"(L) x 38"(W) x 58"(H)

J H Day Mixer Paste Double Arm 20

• Manufacturer: J H Day
• Model Number: 20
• Frain Number: 5A6152

Double sigma mixer. 35 Gallon working capacity (65gl Total capacity). Tangential blade mixer, tilt discharge. Carbon steel contact parts.
Vessel dimensions: 28" in Length; 24" in Width; 24" in Depth.

OAD: 64" W x 90" L x 96" H
