Tablet Rotary Machines

Used Tablet Rotary Equipment

Frain Industries can help you with your rotary tablet press project no matter how big or small your press needs. A rotary tablet press is designed with a rotating disc to provide a pocket into which the powder is deposited and pressed into tablet forms. Rotary tablet presses form tablets as a continuous operation and runs at higher speeds than a single action tablet press.

Tablet Rotary Equipment In Stock

Stokes Press Tablet Rotary DD2

  • Manufacturer: Stokes
  • Model Number: DD2
  • Frain Number: 5H4101

Stokes, Model DD2, 31 station, automatic, rotary tablet press. Rated from 100 to 975 tablets per minute – depending on materials, application, machine configuration and environment being run. Maximum pressure of 8.5 tons. Maximum tablet diameter of (15/16)", Maximum fill depth of 1(1/16)". Equipped with (2) 15"OD x 20" deep stainless steel conical product hoppers, (31) 1" OD keyed upper and 1½" lower round dies. Mounted on heavy duty 72" x 48" base frame. Customer to supply tooling.

OAD: 72"L x 48"W x 85"H

Get a Free Quote Call: 630-629-9900

Key International Press Tablet Rotary DC16 Key International Press Tablet Rotary DC16

Key International Model DC-16, automatic, 16 station rotary tablet press rated from 450 to 770 tablets per minute – depending on size, shape and depth of tablet being run. Maximum operating pressure of 8.5 tons. Maximum tablet diameter round: 15/16", or maximum tablet capsule shaped length of 1". Maximum fill depth: 13/16". Upper plate has (16) 1" ID keyed dies and lower plate has (16) 1-5/8" ID round dies. 12" OD x 25" Deep stainless steel product hopper with brass feed frame and 16" long x 10" wide discharge plate. Vari-speed belt to motor drive, push button start and stop controls and 24" OD pedestal style base. Mounted on 30" long x 30" wide forkable frame. Customer to supply tooling.

OAD: 46" L x 40" W x 71" H With Hopper

Get a Free Quote Call: 630-629-9900

Key International Press Tablet Rotary CMD3B16

Key International, Model CMD3, 16 station rotary press. Rated from 350 to 650 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 8.5 tons. Maximum tablet diameter of (15/16)"; Maximum fill depth of (13/16)". Equipped with 1" OD keyed upper punches and 1½" OD dies and 2 Hp motor to sproket drive. Mounted on 48" x 42" pedestal base frame. Customer to supply tooling.

OAD: 48"L x 42"W x 75"H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 512

Stokes, Model 512, 16 station rotary press. Rated from 350 to 650 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 4 tons. Maximum tablet diameter of (5/8)"; Maximum fill depth of (11/16)". Equipped with ¾" OD keyed upper punches, 1¼" OD dies and 1½ Hp motor to sproket drive. Mounted on 42" x 40" pedestal base frame. Customer to supply tooling.

OAD: 42"L x 40"W x 71"H

Get a Free Quote Call: 630-629-9900

Stokes Press Tablet Rotary 512

  • Manufacturer: Stokes
  • Model Number: 512
  • Frain Number: 5H2805

Stokes, Model 512, 16 station rotary press. Rated from 350 to 650 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 4 tons. Maximum tablet diameter of (5/8)"; Maximum fill depth of (11/16)". Equipped with ¾" OD keyed upper punches and 1(1/8)" OD dies and 1½ Hp motor to sproket drive. Mounted on 36" x 36" pedestal base frame. Customer to supply tooling.

OAD: 46"L x 36"W x 68"H

Get a Free Quote Call: 630-629-9900

Stokes Press Tablet Rotary D3

  • Manufacturer: Stokes
  • Model Number: D3
  • Frain Number: 5H2802

Stokes, Model D3, 16 station rotary press. Rated from 350 to 650 tablets per minute – depending on materials, application, machine configeration and enivorment being run in. Compression: up to 8.5 tons. Maximum tablet diameter of 25.4mm. Equipped with 1" OD keyed dies on upper plate and 1½" OD dies on lower plate. Mounted on 36" x 36" pedestal base frame. Customer to supply tooling.

OAD: 50"L x 38"W x 70"H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 9005181

16 station rotary tablet press rated up to 650 tablets per minute – depending on materials and application. Maximum operating pressure of 4 tons. Maximum tablet diameter round: 11/16", maximum tablet or capsule shaped length of 3/4". Equipped with stainless steel product hopper, brass feed frames, simultaneous top and bottom compression, automatic pressure release and mounted on 36 x 36 base frame. Customer to supply tooling.

OAD: 48" L x 36" W x 72" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary 16 HD

16 station, rotary tablet press rated up to 1200 tablets per minute – depending on materials and application. Maximum operating pressure: 4 tons. Maximum tablet diameter round: 11/16". Maximum tablet diameter 5/8" and maximum capsule shaped length 3/4". Equipped with stainless steel simultaneous top and bottom compression, and automatic pressure release. Mounted on 36 x 36 base frame. Customer to supply tooling.

OAD: 54" L x 40" W x 64" H

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary

Automatic, 10 station rotary tablet press rated to 190 tablets per minute – depending on materials and application. Maximum operating pressure of 3 tons, and maximum tablet dia round of: 15/16" with maximum fill depth of: 13/16" with maximum fill depth of: 13/16" stainless steel product feed hopper and vari-speed belt drive, with push button start / stop controls. Customer to supply tooling.

Get a Free Quote Call: 630-629-9900

Stokes / Compression Component Press Tablet Rotary BB2-D53

33 station rotary tablet press rated up to 1700 tablets per minute – depending on materials and application. Maximum operating pressure of 4 tons. Maximum tablet diameter of 7/16", Maximum fill depth of 11/16". Die diameter: 0.945". Equipped with dual stainless steel product hoppers, keyed uppers, brass feed frames, simultaneous top and bottom compression, automatic pressure release, split discharge chute and mounted on a 33 x 33 base. Customer to supply tooling.

OAD: 51" L x 38" W x 80" H

Get a Free Quote Call: 630-629-9900

Courtoy Press Tablet Rotary R100/36

  • Manufacturer: Courtoy
  • Model Number: R100/36
  • Frain Number: 5D8091

Courtoy Model R100/36, 30 station rotary tablet press rated up to 2850 tablets per minute – depending on materials and application. Tablets: up to .748" diameter x up to .787" fill depth. Has 8.8 tons of compression. Equipped with B type tooling, forced rotary feeders, dust extraction system, 12.99" pitch diameter of turret, air compensator on pre-compression, cooling unit, hydro-pneumatic compensator, 18"L discharge chute with two pneumatic diverter gates and two photoeyes, 10" diameter S/S powder hopper with sight glass, and one piece high strength steel turret with hard chromed working surfaces. Integrated tablet checkweighing system, precompression station with air compensator of 3kN max force, E-stop, and barrier guarding with electrical interlock. Mounted on heavy duty base frame. Customer to supply tooling.

OAD: 82"L x 60"W x 87"H

Get a Free Quote Call: 630-629-9900

Courtoy Press Tablet Rotary R100/24 D tooling, 24 station, 10 ton, to 2266 tpm

  • Manufacturer: Courtoy
  • Model Number: R100/24
  • Frain Number: 5E1510

Courtoy Model R100/24, automatic, 24-station, single sided, satinless steel, rotary tablet press rated from 285 to 2266 tablets per minute – depending on materials and application Equipped with "D" tooling, and has maximum pre-compression force of 1000 lbs, US and main compression force variable up to 10 US tons. Maximum tablet diameter of 25.4mm, and Maximum fill depth of 20mm and can handle Maximum 25.4mm diameter punch, 133.6mm upper, and lower punch lengths, and up to 38.1mm diameter die with heights to 23.8mm. 20" diamete. Equipped with (1) piece steel turret with hard chromed working surfaces and 24 tube stations, stainless steel powder hopper, Courtoy Memo system, that memorizes, monitors and sets all production parameters, with touch pad, monitor screen, and document print out. Also has a auto-weigh system that gives production feedback and can make adjustments on the run. Mounted on stainless steel base frame. Customer to supply tooling.

OAD: 70" L x 96" W x 76" H

Get a Free Quote Call: 630-629-9900
