New England Model NEHBT750AJ, automatic, stainless steel, plastic bulk bottle unscrambler, rated from 50 to 625 container per minute – depending on materials and application. Container size: 3/4" to 8-1/2" in Diameter; up to 13" in Height and is capable of handling a wide variety of sizes and shapes including round, square, oval, straight wall, and handled containers (with proper change parts). Equipped with 72" OD sorting bowl, non scuffing nylon faced transfer, oritentaion and discharge belts, with clear hinged safety doors. Control panel has A/B CPU controls with start, stop and e-stop push button controls. Stainless steel product feed hopper with 60" long x 57" wide x 36" high product hopper and 93" long x 34" wide inclined feed belt with 4" high cleats on 14" centers.
OAD: 108" L x 90" W x 94" H Unscrambler 108" L x 60" W x 100" H Feed Hopper
New England, Model CP48PAMI, Automatic, stainless steel, compact, bulk plastic bottle feeder and unscrambler with number of containers per minute – depending materials, application and machines configuration. Equipped with 36" wide x 70" long x 16" deep bottle hopper with 36" wide live bottom conveyor, vertical bottle elevator with 4" high cleats on 10" centers and 60" discharge height with 48" OD container sorting bowl, capable of handling a variety of sizes and shapes including round, oval, straight-wall, tapered, and non-tapered containers with proper change parts. Orientation wheel with single hook arm container upender, dual soft belt container transfer system. Control panel with PLC controller, push button start / stop and variable speed control dials. Mounted on stainless steel base frame.
OAD: 112" L x 74" W x 75" H
New England, Model NEHCP60, Automatic, compact, stainless steel bulk bottle unscrambler with number of containers per minute – depending on materials and application. Equipped with 52" wide x 230" long x 16" deep bulk bottle hopper with 36" wide x 216" long live bottom conveyor, 34" wide vertical bulk bottle elevator with 6½" high cleats set on 14" centers, 60" OD bottle sorting bowl, with bottle size range: 5/8" to 6½" in Diameter x up to 12" in height and is capable of handling variety of sizes and shape containers including round, oval, straight-wall, tapered and non-tapered with proper change parts. 20" OD rotary orientation wheel with single hook arm container upender, (2) sets of 1½" wide x 32" long dual soft belt container transfer system. Control panel has AB controller with touch screen HMI. Mounted on stainless steel frame with safety door guarding.
OAD: 270"L x 91"W x 110"H
New England, Model NEBHHBTCEL-60, Automatic, stainless steel, compact, easy access, bulk plastic bottle feeder, cleaner and unscrambler. Equipped with 64" wide x 60" long x 34" deep empty bottle hopper with 35" wide x 40" long live bottom conveyor 35" wide vertical bottle elevator with 3¾" high cleats on 12" centers, 60" OD container sorting bowl with container size range of (5/8)" to 6½" OD x up to 12" in Height and capable of handling variety of sizes and shapes including round, oval, straight-wall, tapered and non-tapered containers with proper change parts. 20" OD rotary orientation wheel with single hook arm container upender, ionized air bottle cleaning station and (3) sets of 1½" wide x 24" long dual soft belt container transfer system. Control panel has an A/B controller with push button start / stop controls. Mounted on stainless steel frame with interlock safety guarding doors. Speed dependent on materials, application and machine configuration.
OAD: 177"L x 84"W x 104"H
New England, Model NEHCPCL-48, automatic, stainless steel, compact, bulk plastic bottle feeder and unscrambler, rated from 20 to 120 containers per minute – depending materials and application. Equipped with 42" wide x 78" long x 12" deep (20 ft³) bottle hopper with 28" wide x 64" long live bottom conveyor, 26" wide vertical bottle elevator with 4½" high cleats on 10" centers, 48" OD container sorting bowl, with container size range: (5/8)" to 6½" in Diameter x up to 12" in Height and capable of handling variety of sizes and shapes including round, oval, straight-wall, tapered, and non-tapered containers with proper change parts. 20" OD rotary orientation wheel with single hook arm container upender, ionized air and vacuum container cleaner, (3) sets of dual soft belt container transfer system all 1½" wide with 18" long thru cleaner, 18" long transfer from cleaner to 24" long discharge section. Mounted on stainless steel base frame.
OAD: 125"L x 80"W x 90"H
Posimat Access Series, Model N-15 bulk container unscrambler, rated from 80 to 200 containers per minute – depending on materials and application. Equipped with 48" OD container accumulation disc, with (14) horizontal polyethylene quick change container pockets and (14) vertical stainless steel 24" long quick change container funnels, 120" long x 3-1/2" wide left to right vacuum assist product discharge conveyer, e-stop, digital read out for bottle count, production rates and speeds per minute. Pockets and funnels snap in / out for quick change tool-less adjustments, 304 stainless steel enclosed construction, has double front, and one side door for easy access. with start, stop and e-stop push buttons. Mounted on stainless steel frame with safety doors. Last running round plastic bottles in a cosmetic operation.
New England, Model H/E-40, stainless steel incline cleated belt feeder with number of containers per hour – depending on materials and application. Equipped with 52" wide x 52" long x 35" deep (15 ft³) stainless steel product hopper, 18" wide x 85" long belt conveyor with 4" high cleats set on 12" centers and 65" discharge height. Powered by ½ Hp motor drive. Mounted on stainless steel frame with leveling pads.
OAD: 150" L x 70" W x 96" H (unscrambler)OAD: 100" L x 52" W x 91"H (feeder)
New England, Model NEHCPCL-60, Automatic, stainless steel, compact, easy access, bulk plastic bottle unscrambler, cleaner and feeder with number of containers per minute – depending on materials and application. Container size range of (5/8)" to 6½" OD x up to 11" in Height and is capable of handling variety of size and shape containers including round, rectangle, oval and square with proper change parts. Anodized aluminum and 304 stainless steel construction with clean, non-painted, non-marring surfaces with smoothed and polished welds. Equipped with 50 cu ft empty container hopper with 36" wide x 84" long bottom container conveyor with 36" wide x 48" high vertical empty container elevator has 7" high cleats set on 14" centers with 60" OD container sorting bowl, accelerator and orienter belts with single hook arm container upender, ionized air bottle cleaning station with container soft belt timing and transfer system with backlog photo eye and has automatic stop and restart. Control panel has A/B Micro Logix controller with HMI interface and elevator and bowl speed control dials, with start, stop and e-stop push buttons. Mounted on tubular 304 stainless steel frame with interlock safety door guarding.
OAD: 120" L x 90" W x 87" H
New England Model NEHCL250, automatic, stainless steel, bulk plastic bottle unscrambler. Rated from 50 to 350 containers per minute – depending materials and application. Container size range: (5/8)" to 6½" in Diameter x up to 10" in Height and is capable of handling a variety of sizes, and shapes including round, oval, straight-wall, tapered and non tapered containers. Equipped with bulk cap feeder, 48" sorting bowl, 20" diameter rotary orientation wheel with single hook arm container upender, ionized air and vacuum container cleaner, (3) sets of dual soft belt container transfer system all 1½" wide with (1) 32" long thru cleaner, (1) 20" long transfer from cleaner to discharge and (1) 26" long discharge section. Control box with bowl, orient, belt out, speed control dials, start, stop, and e-stop buttons. Mounted on stainless steel base frame with interlocking lexan guarding.
OAD: 101"L x 65"W x 83"H
Njm, Model Unisort 32, automatic, stainless steel, compact, bulk plastic bottle unscrambler. Rated from 20 to 200 containers per minute – depending on materials and application. Container size range: 35cc to 950cc and 1" to 4" OD x 1.5" to 7.5" in Height. and capable of orienting round, square, rectangular containers (with proper change parts). Equipped with floor level 52" long x 38" wide x 25" deep stainless steel container feed hopper with 46" long x 12" wide cleated belt feeder and 3" high cleats set on 11½" centers with plastic safety covers, 32" OD sorting bowl, with non scuffing nylon face, transfer, orientation and discharge belts, with Seko guages. Control panel has A/B controller with touch screen HMI and statis light bar. Mounted on stainless steel (4) leg frame.
OAD: 110"L x 64"W x 71"H
New England, Model NEHCPCL-36, Compact, automatic, stainless steel, bulk plastic container feeder and unscrambler rated from 20 to 120 containers per minute – depending materials and application. Equipped with 20" wide x 60" long white flexlink container feed conveyor to 70" long x 19" wide vertical cleated container elevator with 4-3/4" wide cleats set on 14" centers to 36" OD container sorting bowl, with container size range of (5/8)" to 6½" OD x up to 10" in Height and capable of handling variety of sizes and shape containers including round, oval, straight-wall, tapered, and non-tapered with proper change parts. 14" OD rotary orientation wheel with single hook container arm upender, (4) sets of dual soft container transfer belts all 1½" wide with a 14" long belt thru cleaner, 19" long transfer belt from cleaner to 24" and 32" long container discharge belts. Control panel has (8) A/B PowerFlex variable speed controllers with auto / manual switch and reset, jog, start, stop and e-stop push buttons. Mounted on stainless steel base frame.
OAD: 68" L x 84" W x 85" H
New England, Model NEHCP-36, Compact, automatic, stainless steel, bulk plastic container feeder and unscrambler rated from 20 to 120 containers per minute – depending materials and application. Equipped with 20" wide x 60" long white flexlink container feed conveyor to 70" long x 19" wide vertical cleated container elevator with 4-3/4" wide cleats set on 14" centers to 36" OD container sorting bowl, with container size range of (5/8)" to 6½" OD x up to 10" in Height and capable of handling variety of sizes and shape containers including round, oval, straight-wall, tapered, and non-tapered with proper change parts. 14" OD rotary orientation wheel with single hook container arm upender, (4) sets of dual soft container transfer belts all 1½" wide with a 14" long belt thru cleaner, 19" long transfer belt from cleaner to 24" and 32" long container discharge belts. Control panel has (8) A/B PowerFlex variable speed controllers with auto / manual switch and reset, jog, start, stop and e-stop push buttons. Mounted on stainless steel base frame.
New England, Model NEHCPE-60, automatic, stainless steel, compact, easy access, bulk plastic bottle feeder and unscrambler. Equipped with a 51" wide x 90" long x 15" deep (40 ft³) bottle hopper with a 35" wide x 72" long live bottom conveyor, 34" wide vertical bottle elevator with 6" high cleats on 12" centers, 60" OD container sorting bowl, with container size range: (5/8)" to 6½" in Diameter x up to 12" in Height and capable of handling variety of sizes and shapes including round, oval, straight-wall, tapered, and non-tapered containers with proper change parts. 20" OD rotary orientation wheel with single hook arm container upender, (2) sets of 1½" wide x 32" long dual soft belt container transfer system. Control panel has an AB controller with an AB PanelView 600 touch screen display. Mounted on stainless steel base frame. Speed dependent on materials, application an machine configuration.
OAD: 115"L x 85"W x 93"H
