Automatic Glue Cartoner
Adco, Model 9SBBC-175-SS, Automatic, horizontal, continuous motion, open balcony design, hot melt glue cartoner. Rated from 25 to 175 cartons per minute – depending on materials, application and machine configuration. Carton size range: 1" to 6½ in Length; 1" to 3¼" in Width, 3" to 10½" in Depth. Equipped with adjustable chains set on 9" centers, 8" wide x 90" long in feed conveyor, chain aligner into (2) chain product in feed conveyor with up stacker to (1) chain lugged carton conveyor set on 9" centers, with 72" long (3) belt powered blank carton magazine, (2) head rotary pic-n-place, with pre-break, no-product / no-carton, barrel cam loader, Nordson ProBlue hot melt glue system, major and minor flap closers, 24" long compression discharge belt conveyor section, Seko gauges, vacuum pump, lube system and interlock safety guarding. Control Panel has A/B PLC with touch screen HMI. Mounted on heavy duty base frame with caster and leveling legs.
OAD: 340"L x 72"W x 88"H
Serpa, Model 5000 CAL, Automatic, stainless steel, horizontal, glue cartoner rated from 50 to 200 cartons per minute – depending on materials and application. Maximun carton size of 4" in length; 4" in Width; 9" in Depth. Equipped with 80" long load area with adjustable product buckets, 36" Leaflet magazine with 3-head rotary pic n place, leaflet verification eye, 40" blank carton magazine, 2-head rotary carton pic n place with carton prebreak, 3 chains adjustable set on 6" centers with 3" High lugs, overhead product hold down and Siko gauges for quick product change-overs. Control panel with A/B controls and touch screen HMI. Mounted on multi-leg frame.
OAD: 230"L x 75"W x 84"H
Adco, Model 15DBC105-SS, Automatic, stainless steel, horizontal, continuous motion, hot melt glue cartoner rated from 25 to 120 cartons per minute – depending on materials and application. Carton size range: 1" to 9" in Length; 3/4" to 3" in Width 4" to 12" in Depth. All stainless steel construction. Equipped with (4) chains adjustable set on 12" centers with 3" wide x 4" high lugs, 72" long x 12" wide fixed product in feed conveyor with 1-1/2" high cleats set on 5" centers, 48" long (3) belt automatic blank carton magazine, (2) head rotary pic-n-place with pre-break, top squaring device, barrel cam product loader, Nordson hot melt glue system, major and minor flap closers. Control panel has A/B PLC with A/B Panelview touch screen HMI controls. Mounted on stainless steel frame with safety guarding, casters and leveling legs.
OAD: 324" L x 84" W x 72" H
Climax, Model C3, automatic, intermittent motion, 6 lane, side load, hot melt glue cartoner. Rated up to 15 cartons per minute – depending on materials, application, pack pattern and machine configuration. Capable of running 4 packs, 6 packs, 8 packs of 12oz and 16oz cans and 12 packs, 15 packs, 18 packs and 24 packs of 12oz cans with proper change parts. Equipped with (6) 16" wide x 60" long container feeder chutes to container orientation laner with (1) 6" wide x 282" long conveyor, (1) 6" wide x 190" long conveyor and (1) 6" wide x 96" long conveyor, (1) 18" wide x 98" long infeed conveyor, automatic blank carton magazine and pick n place, carton collation section with air knife carton open assist, set on 15" centers with 2" wide x 4" long lugs, single arm loader, Nordsen ProBlue hot melt glue system, minor / major flap closers, compression section, seko gauges and safety guarding. Control panel has A/B PLC with A/B panel view controls with A/B variable speed controllers. Mounted on carbon steel frame with two part stainless steel epoxy paint primer and finish coat with leveling legs.
OAD: 450"L x 100"W x 67"H
IWKA Model SC6, Automatic, horizontal, continous motion, hot melt glue cartoner rated from 50 to 300 cartons per minute depending on materials and application. Package size range: 20mm to125mm in Length; 15mm to 110mm" in Width; 50mm to 85mm in height. Equipped with 64" long x 3" wide product in feed conveyor with worm screw indexing to 163" long fixed bucket product conveyor, with 3" long x 2" wide x 9" deep product buckets, 48" long (3) belt automatic blank carton magazine, (2) head rotary pick n place. and has (2) chains fixed set on 3" centers, automatic barrel cam product loader, Nordson hot melt glue system, Seko guages and 32" long x 2-1/2" wide discharge compression belts. Control panel has IWKA controller with swing arm touch pad controls and panel view with e-stop push buttons and statis light bar. Mounted on heavy duty frame with interlock safety guarding, casters and leveling legs.
OAD: 303" L x 72 " W x 92" H
Adco, Model 15DBC105-SS, automatic, horizontal, continuous motion, hot melt glue cartoner, rated from 25 to 120 cartons per minute – depending on materials and application. Non washdown stainless steel construction. Carton size range: 1" to 9½" in Length; 3¾" to 4" in Width 4.5" to 12" in Depth. Equipped with (4) corrosion resistant coated adjustable chains set on 12" centers with 3½" high lugs. 140" long lugged product in feed conveyor, 48" long (3) belt automatic blank carton magazine, (2) head rotary pic n place carton feeder with pre-break and top squaring device, no product / no carton, no carton / no load sensors, barrel cam product loader, Nordson Problue (2) gun hot melt glue system, major and minor flap closers, vacuum pump, Seko adjustment gauges and 32" long dual sidebelt discharge conveyor. Control panel has A/B PLC controller and A/B Panelview touch screen HMI controls with start, stop, e-stop push buttons and 4-color stack light. Mounted on stainless steel frame with interlock safety guarding, casters and leveling legs.
OAD: 360" L x 90" W x 72" H
Adco, Model 15DBC105-SS, automatic, horizontal, continuous motion, all stainless steel construction hot melt glue cartoner. Rated from 25 to 120 cartons per minute – depending on materials and application. Carton size range: 1" to 9½" in Length; 3¾" to 4" in Width 4" to 12" in Depth.. Equipped with (4) chains adjustable set on 12" centers with 3½" high lugs. 48" long (3) belt automatic blank carton magazine, (2) head orbital pic-n-place with pre-break, top squaring device, barrel cam product loader, Nordson Problue hot melt glue system, major and minor flap closers, Seko adjustment gauges and 32" long dual sidebelt discharge conveyor. Control panel has an A/B PLC with A/B Panelview touch screen HMI. Mounted on stainless steel base frame with interlock safety guarding, casters and leveling legs.
OAD: 360"L x 90"W x 72"H
Jones Model Criterion II, Automatic, horizontal, high speed, servo driven, continuous motion, hot melt glue cartoner, with number of cartons per minute – depending on materials and application. Equipped with (3) chains adjustable set on 15" centers with 5-1/2" high x 1" wide lugs. Carton size range: 2-1/2" to 14" in Length; 3/4" to 4" in Width; 6" to 12" in Depth. Equipped with 142" long total, (3) smart belt product in feed conveying system, with automatic (2) belt blank carton magazine, (2) head rotary carton pic n place, with camera verification system, no product / no carton, barrel cam product loader, with rotary top confiner, Nordson ProBlue hot melt glue system, major and minor flap closers with Seko gauges and compression section. Control panel has A/B controller and A/B panelview with multiple start, stop, jog, reset and e-stop push buttons sections. Mounted on heavy duty frame with interlock safety door guarding and leveling legs.
OAD: 567" L x 108" W x 85" H
Tisma Model TCH 600L, Automatic, continuous motion, horizontal, hot melt glue cartoner rated from 50 to 250 cartons per minute – depending on materials and application. Carton size range: 1-1/2" to 5" in Length x 1/2" to 3-3/4" in Width x 3" to 9" in Depth. Equipped with (4) chains adjustable set on 6" centers, with 1-1/2" wide x 1-1/2" high lugs, 32" long x 4" wide product feed conveyor to 120" long total and 95" long usable product hand load bucket in feed conveyor with 4-3/4" long x 1" wide x 11-1/2" deep fixed product buckets. 60" long (2) chain automatic blank carton magazine, (4) head rotary pic n place, top hold down squaring bar, no product / no carton and low blank sensors, automatic barrel cam product loader, Nordson hot melt glue system, with carton flap closers and dual 24" long x 1" high side belt compression / discharge conveyor. Control panel, has CPU controller and A/B panelview with readout, cycle start / stop, pusher cylinder on / off, jog / run, product hold down / up / down switches and e-stop controls. Mounted on multi-leg heavy duty frame with interlock safety doors and statis light.
OAD: 383" L x 89" W x 70" H Machine Only 181" W With End Conveyors
Adco Model 15DBC105EC, automatic, continuous motion, horizontal, hot melt glue cartoner rated from 25 to 125 cartons per minute – depending on materials and application. Carton size range: 1" to 9-1/2" in Length; 3/4" to 3" in Width 4 to 12" in Depth. Equipped with (4) chains adjustable set on 12" centers and has 192" long x 12" wide fixed product pocket in feed conveyor with 12" long x 12" wide 1-1/2" high product pockets. Automatic (3) belt blank carton magazine, (2) head rotary pic-n-place, with pre-break, no-product / no-carton, top carton hold down, barrel cam loader, Nordson hot melt glue unit and built in vacuum system. Control Panel has relay logic controller with machine, vacuum, speed, pattern control with jog / run, on / off switches and start, stop, e-stop push button controls and statis lights. Mounted on heavy duty height adjustable frame with caster with leveling legs and interlock safety guarding.
Emboss Coder Available At Additional Cost
OAD: 285" L x 92" W x 76" H
PART OF 5H2660A Adco, Model 9LBC150EC, Automatic, horizontal, continuous motion, hot melt glue cartoner. Rated from 50 to 250 cartons per minute – depending on materials, application and machine configuration. Carton size range: 1" to 7" in Length; 3/4 to 4" in Width, 4-1/4" to 13-1/2" in Depth. Equipped with (4) chains adjustable set on 9" centers with 2" wide x 4" high lugs and has 264" long x 15" wide product in feed conveyor with 2-1/2" long x 2-1/2" wide x 15" deep product buckets, 108" long (4) belt powered blank carton magazine, (4) head rotary pic-n-place, with pre-break, no-product / no-carton, top carton hold down, barrel cam loader, Nordson ProBlue hot melt glue system, major and minor flap closers, 48" long compression discharge belt conveyor section, Seko gauges, vacuum pump, lube system and interlock safety guarding. Control Panel has A/B PLC, with A/B swing arm touch pad controller and panel view with reset / e-stop controls and (4) color stack light. Mounted on heavy duty base frame with caster and leveling legs.
OAD: 364" L x 96" W x 84" H
Thiele, Model 60S-SP, automatic, continuous motion, stainless steel, horizontal, hot melt glue cartoner. Rated from 60 to 400 cartons per minute – depending on materials and application. Carton size range 1" to 3-1/2" in Length; 1/2" to 3-1/2 in Width; 2-3/4" to 4-1/2" in Depth Equipped with (2) chains and 246" long in feed conveyor with 3-1/2" long x 2" wide x 7-3/8" deep fixed product buckets, auto blank carton magazine, (4) head rotary pic and place, (2) chain carrier system set on 5" centers, with 1-1/2" high x 1/2" wide" lugs, no carton / no product / no product / no carton, barrel cam auto load section, Nordson hot melt glue system, major and minor flap closers, 48" long compression section, interlocking Lexan safety guarding and statis light bar. Control panel has CPU controller with start, stop, e-stop controls. Mounted on heavy duty base frame.
OAD: 310" L x 72" W x 78" H Without In Feed 546" L With In Feed
