VolumetricScale Machines

Paxall Cartoner Auto VolumetricScale C4

• Manufacturer: Paxall
• Model Number: C4
• Frain Number: 5H4456

Paxall, Model C4, automatic, vertical, 4 pocket volumetric, continuous motion, hot melt glue cartoner. Rated from 20 to 100 cartons per minute – depending on materials, application and machine configuration. Carton Size: 2" to 8¼" long x ¾" to 3¼" wide x 4¼" to 11¼" deep. Equipped with single chain currently set on 10" centers with 64" long (2) chain powered blank carton magazine, recipicating vacuum suction cup pick n place, 5½" long; 2½" wide; 3" deep fixed product buckets and (4) pocket rotary tapered product funnels and Nordson hot melt glue systyem. Control panel has drive jog, off , run and cartoner main and auto switches with vacuum, cycle, jog, reset, and start, stop, e-stop push button controls. Mounted on heavy duty base frame.

OAD: 140" L x 90" W x 70" H

Clybourn Cartoner Auto VolumetricScale C8

• Manufacturer: Clybourn
• Model Number: C8
• Frain Number: 5H3608

Clybourn, Model C8, automatic, continuous motion, vertical cartoner. Rated from 80 to 200 cartons per minute depending on materials, application and machine configuration. Carton size range: 1" to 4" in Length; 3/8" to 2-1/2" in Width; 4-1/8" to 8" in Depth. Equipped with 64" long blank carton magazine, reciprocating pick and place, single chain carrier system currently set on 5" centers, bottom flap closers and plows and eight pocket rotary volumetric filling station with no carton / no fill. Control panel with on / off switches and push button start / stop controls. Mounted on heavy duty base frame.

OAD: 190" L x 42" W x 90" H

Clybourn Cartoner Auto VolumetricScale C8

• Manufacturer: Clybourn
• Model Number: C8
• Frain Number: 5H3609

Clybourn, Model C8, automatic, continuous motion, vertical cartoner. Rated from 80 to 200 cartons per minute depending on materials, application and machine configuration. Carton size range: 1" to 4" in Length; 3/8" to 2-1/2" in Width; 4-1/8" to 8" in Depth. Equipped with 64" long blank carton magazine, reciprocating pick and place, single chain carrier system currently set on 5" centers, bottom flap closers and plows and eight pocket rotary volumetric filling station with no carton / no fill. Control panel with on / off switches and push button start / stop controls.Mounted on heavy duty base frame.

OAD: 190" L x 42" W x 90" H

Adco Cartoner Auto VolumetricScale 15VEC

• Manufacturer: Adco
• Model Number: 15VEC
• Frain Number: 5H2542

Adco Model 15VEC, automatic, vertical, continuous motion, hot melt glue cartoner, rated from 30 to 120 cartons per minute – depending on materials and application. Carton size range: 1 to 10" in Length x 3/4′ to 4" in Width x 1" to 10" in Depth, with proper change parts. Equipped with 2 chains, set on 8" centers with 72" Long (2) chain powered blank carton magazine, (2) head rotary pic-n-place, (5) funnel rotary product feed system, Nordson (2) gun hot melt glue system. Control panel with start / stop / jog and a/c drive controlls with e-stops. Mounted on heavy duty base frame with interlock safety guarding.

OAD: 288" L x 70" W x 88" H

Clybourn Cartoner Auto VolumetricScale C

• Manufacturer: Clybourn
• Model Number: C
• Frain Number: 5C2811

Vertical continuous motion 10" center Cartoner with 12 pocket spout oval transfer buckets for powder guide into cartons. Has carton range of: 1.00" – 8.25" Long x 0.75" – 3.25" Wide x 4.25" – 11.25" Deep with proper change parts. Capable of speeds from 40 to 80 cpm – speeds depending on materials and application. Includes shaker option on carton guide base which shakes the cartons as they are filled. Machine set for hot-melt carton closure. Reciprocating magazine feed

Clybourn Cartoner Auto VolumetricScale AH-8

• Manufacturer: Clybourn
• Model Number: AH-8
• Frain Number: 5C0584

High speed vertical cartoner with volumetric filler with rated filling speeds from 20 to 100 per minute – speeds depending on materials and application. 8 Pocket volumetric filler. 5′ long carton magazine. 4" centers. Carton size range: 3/4" – 2 1/2" long x 3/8" – 1 1/4" wide x 2 3/4 " – 7 1/2" deep. Includes vibrator for product settling. LTI spot wheel glue system. Optional emboss coder is available.

Clybourn Cartoner Auto VolumetricScale SPECTRUM

• Manufacturer: Clybourn
• Model Number: SPECTRUM
• Frain Number: 5H1960

Clybourn Model Spectrum, automatic, continuous motion, vertical, hot melt glue cartoner with carton size and number of cartons per minute – depending on materials and application. Equipped with (1) chain and has 6-1/2 long x 5-1/2 wide x 1-1/2" deep fixed product buckets set on 7" centers, 100" long (2) chain powered blank carton magazine, (1) head recipricating pic in place, 36 pocket rotary product funnel filling system with vibratory motors to settle product and Nordson hot melt glue system. Remote control panel has A/B CPU, variable speed drive and on board control panel with half and full fill, jog, run, carton set-up and by pass on and off switches with speed control dial and on, off, e-stop push buttons. controls. Mounted on heavy duty base frame with interlock safety guarding.

OAD: 269" L x 60" W x 69" H Cartoner
100" L x 20" W x 36" H Carton Magazine

Clybourn Cartoner Auto VolumetricScale

• Manufacturer: Clybourn
• Model Number:
• Frain Number: 5H1961

Clybourn, automatic, continuous motion, vertical, hot melt glue cartoner with carton size and number of cartons per minute – depending on materials, application and machine configeration. Equipped with (2) chains with 6-1/2 long x 5-1/2 wide x 1-1/2" deep fixed product buckets set on 7" centers has a 72" long (2) chain powered blank carton magazine, (4) head rotary pick in place, 16 pocket rotary product funnel filling system with vibratory motors to settle product and Nordson hot melt glue system. Control panel has A/B controller, with variable speed drive and remote control panel with touch pad controls and digital readout with glue, jog, run, carton feed, vacuum, product feed, turret run, level control on, off switches and start, stop, e-stop push buttons controls. Mounted on heavy duty base frame with interlock safety guarding.

OAD: 132" L x 48" W x 64" H Cartoner
72" L x 20" W x 36" H Carton Magazine

Triangle Cartoner Auto VolumetricScale PROLINE

• Manufacturer: Triangle
• Model Number: PROLINE
• Frain Number: 5H0651

Triangle Model Proline Series, automatic vertical, hot melt glue cartoner with number of cartons per minute – depending on materials, application and machine configuration. Size range: per application. Equipped with 2 chains fixed set on 10" centers with 7" long; 5-3/4" wide; 4" deep fixed product buckets. 72" long (2) chain powered blank carton magazine, (4) head rotary pick in place, (2) chains (4) 5" ID pocket rotary product filling system with (4) 8" long x 6-1/2" wide x 14" high stainless steel product funnels with dust removal system and Seko gauges. Control panel has A/B CPU, with A/B Panelview and A/B variable speed drive controllers, run, jog, drive speed, power on / off and with product and without product switches, start, stop and e-stop push button controls with increase and decrease product buttons at each end of the cartoner. Mounted on heavy duty base frame with locking safety guarding.

*Optional Spout Inserter Available For An Additional Cost.

OAD: 208" L x 168" W x 98" H Fully Assembled

Clybourn Cartoner Auto VolumetricScale 312-E

• Manufacturer: Clybourn
• Model Number: 312-E
• Frain Number: 5F6991

Clybourn, Model 312-E, Spectrum series, automatic vertical, hot melt glue, cartoner rated from 40 to 110 cartons per minute – depending on materials and application. Size range: 3" to 10" in length; 1-1/2" to 4" in Width; 5" to 12" in Depth with proper change parts. Single chain unit currently set on 12" centers with 7-1/2 in Length; 2-1/4 in Width; 4" in Depth fixed product buckets. Equipped with 130" long (2) chain powered blank carton magazine, dual head rotary pick in place, 6 pocket rotary product funnel filling system with vibratory motors to settle product. A/B CPU, Electro Cam Plus 5000 touch pad with readout, variable speed drive controller and interlock safety guarding.

OAD: 240" L x 84" W x 77" H Cartoner
130" L x 20" W x 36" H Carton Magazine

Clybourn Cartoner Auto VolumetricScale C4

• Manufacturer: Clybourn
• Model Number: C4
• Frain Number: 5G9620

Clybourne, Model C4, automatic, vertical, 4 pocket volumetric, continuous motion, hot melt glue cartoner. Rated from 20 to 100 cartons per minute – depending on materials, application and machine configuration. Carton Size: 2" – 8¼" long x ¾" – 3¼" wide x 4¼" – 11¼" deep. Equipped with single chain currently set on 10" centers with 68" long (2) chain powered blank carton magazine, recipicating vacuum suction cup pick n place, 8" long; 2" wide; 6" deep fixed product buckets and (4) pocket rotary volumetric product feeder with 6" ID x 6" deep product pockets set on 13½" centers and (4) 8" long x 8" wide x 6" high tapered product funnels and Nordson hot melt glue systyem.

OAD: 120"L x 40"W x 79"H (Cartoner)
72"L x 28"W x 47"H (Magazine)

Clybourn Cartoner Auto VolumetricScale A-16

• Manufacturer: Clybourn
• Model Number: A-16
• Frain Number: 5G5888

Clybourne Model A-16, automatic, vertical, 16 pocket volumetric, continuous motion, hot melt glue cartoner rated from 20 to 100 cartons per minute – depending on materials and application. Equipped with 1 chain currently set on 2" centers with 62" long (2) chain powered blank carton magazine, recipicating vacuum suction cup pick n place and carton formers, 1-1/2" long; 2" wide; 1/2" deep fixed product buckets and (16) pocket rotary volumetric product feeder with 1-1/4" ID x 1/4" deep product pockets set on 2-1/2" centers and (8) 3" long x 2" wide x 5" high tapered product funnels and Nordson hot melt glue systyem. Control panel with start, stop, e-stop push buttons, jog, run auto and vibrator switches with saftey guarding.

OAD: 84" L x 53" W x 74" H
