Automatic Horizontal Tuck Machines

Automatic Horizontal Tuck Equipment In Stock

Redington Cartoner Auto Horiz. Tuck (Auto) 23D24

  • Manufacturer: Redington
  • Model Number: 23D24
  • Frain Number: 59265

Specifications- automatic, horizontal, continuous, reverse tuck, centers 4", : capable of speeds from 80 to 200 cpm – speeds depending on materials and application. Complete with automatic barrel loader, verticle carton magazine, and an adjustable bucket infeed conveyor (last running 4 carton sizes). Equipped with Allen Bradley SLC 5/01 PLC system; Has Lexan barrier guarding. Price includes set to one carton size (subject to receipt of samples). Options available include automatic bottle loader.
On skid 17′ 1" long by 6′ 1" wide.

Get a Free Quote Call: 630-629-9900

IWKA Cartoner Auto Horiz. Tuck (Auto) CP160

  • Manufacturer: IWKA
  • Model Number: CP160
  • Frain Number: 5E4331

Automatic continuous motion, horizontal tuck cartoner capable of speeds from 50 to 160 cpm – speeds depending on materials and application. Carton size range: 3/4" to 5" in length; 5/8" to 3 1/8" in width; 3 1/8" to 9 7/8" in depth. Equipped with 3 chain adjustable system, set on 6" centers, 48" long blank carton magazine no product/no carton and barrel cam loader, flap tuckers and closers. Control panel with IWKA controller and e-stop.

Available at additional cost:
IWKA Tube Feeder
GUK model RS/21/760 roll fed leaflet feeder
Emboss Coder

OAD: 198” L x 84" W x 72" H

Get a Free Quote Call: 630-629-9900

Econocorp Cartoner Auto Horiz. Tuck (Auto) SPARTAN 15709

  • Manufacturer: Econocorp
  • Model Number: SPARTAN 15709
  • Frain Number: 5E3710

Automatic, intermittent motion, tuck cartoner. Carton size range: 2" to 10" in Length; 1" to 4" in width; 5" to 12" in Depth. Equipped with product in feed conveyor, mechanical product load station, blank carton magazine, reciprocating pick & place, lugged product conveyor, tuck closing mechanism and Lexan guarding. Mounted on height adjustable legs. Speed dependant on materials, application and machine configuration

OAD: 204"L x 60"W x 54"H

Get a Free Quote Call: 630-629-9900

Cam Cartoner Auto Horiz. Tuck (Auto) PRX

  • Manufacturer: Cam
  • Model Number: PRX
  • Frain Number: 5E0021

Automatic, intermittent motion, horizontal, walking beam, tuck cartoner capable of speeds from 30 to 60 cpm – speeds depending on materials and application. Cartons size range: 1/2" – 3 1/2" L x 1/2" – 2" W x 2" – 7 3/4" D, has adjustable bucket in feed, right angle product pusher into carton, dual walking beam drive on 4-3/4" centers, 27" L magazine, reciprocating vacuum pic-n-place, top carton squaring mechanism and e-stop. AB SLC 5/04 with Panel View, integrated vacuum pump, changeover gauges and barrier guarding with electrical interlock, and is mounted on stainless steel frame with casters and height adjustable legs.

OAD: 130" L x 59" W x 75" H

Product timing in feed, dry-ink coder, and literature placer available at additional cost.

Get a Free Quote Call: 630-629-9900

Thiele Cartoner Auto Horiz. Tuck (Auto) C50

  • Manufacturer: Thiele
  • Model Number: C50
  • Frain Number: 5G9616

Thiele, Model C-50, automatic, continuous motion, horizontal, reverse tuck cartoner. Rated from 60 to 300 cartons per minute – depending on materials, application and machine configuration. Carton Size Range: ¾" to 4½" in Length; (3/8)" to 3" in Width; 1½" to 7" in Depth. Equipped with a star wheel auto loader, 100" long product in feed conveyor with 1½" long x ¼" wide x 7" deep product buckets, 84" long blank carton magazine, (4) head rotary pic and place, single chain carrier system set on 5" centers, barrel cam loading section, barcode scanner, 24" long compression section and interlocking Lexan safety guarding. Control panel has an AB controller with push button start / stop controls for drive and vacuum, variable speed dial and run / jog switch.

OAD: 300"L x 68"W x 70"H

Get a Free Quote Call: 630-629-9900

Z Automation Company Inc /ZAC Cartoner Auto Horiz. Tuck (Auto) CH7.510I

Z Automation Company, Model CH 7.5-10-I, automatic, horizontal, intermittent motion, tuck cartoner. Rated from 5 to 20 cartons per minute – depending on materials, application and machine configuration. (1) chain unit currently set on 7½" centers with 2" wide x 5" high fixed lugs. Equipped with 4" wide x 88" long incline eagle belt product feeder, 16" high product down stacker, swinging product stack transfer arm, push arm auto loader and 16" long adjustable carton magazine with reciprocating suction cup pick and place. Control panel has A/B CPU with panel view and push button controls, status light bar and interlocking safety guarding. Mounted on stainless steel base frame.

OAD: 208" L x 78" W x 76" H

Get a Free Quote Call: 630-629-9900

Z Automation Company Inc /ZAC Cartoner Auto Horiz. Tuck (Auto) CH7.510I

Z Automation Company, Model CH 7.5-10-I, automatic, horizontal, intermittent motion, tuck cartoner. Rated from 5 to 20 cartons per minute – depending on materials, application and machine configuration. (1) chain unit currently set on 7½" centers with 2" wide x 5" high fixed lugs. Equipped with 4" wide x 88" long incline eagle belt product feeder, 16" high product down stacker, swinging product stack transfer arm, push arm auto loader and 24" long adjustable carton magazine with reciprocating suction cup pick and place. Control panel has A/B CPU with panel view and push button controls, statis light bar and interlocking safety guarding. Mounted on stainless steel base frame.

OAD: 240" L x 78" W x 80" H

Get a Free Quote Call: 630-629-9900

Nordale / AFA Systems Inc Cartoner Auto Horiz. Tuck (Auto) MK APS

Nordale Model MK APS, automatic, horizontal, intermittent motion, servo driven, stainless steel, tuck cartoner with number of cartons per minute – depending on materials and application. 3 chains adjustable currently set on 6" centers with 2" wide x 2" high lugs. Equipped with 32" long leaflet magazine with recpicating suction cup pick n place, 40" long x 2" wide product in feed belt conveyor to star wheel bottle feed with 84" long sliding style adjustable product bucket conveyor, 60" long (2) belt automatic blank carton magazine with 2 head rotary suction cup pick n place, no product / no carton, carton squaring top hold down bar, dual product recipicating loading arms, major and minor flap plows and closers with 36" long compression section. Control panel has A/B CPU with panel view and push button controls, statis light bar and interlocking safety guarding. Mounted on stainless steel base frame with casters.

Coder Available At Addition Cost

OAD: 200" L x 69" W x 79" H

Get a Free Quote Call: 630-629-9900

Marchesini Cartoner Auto Horiz. Tuck (Auto) BA 100

  • Manufacturer: Marchesini
  • Model Number: BA 100
  • Frain Number: 5G0884

Marchesini Model BA 100, automatic, intermittent motion, horizontal, cartoner rated from 10 to 60 cartons per minute – depending on materials and application. Carton size range: 20mm to 110mm in Length; 12mm to 55mm in Width; 55mm to 170mm in Depth with proper change parts. Equipped with (3) adjustable carton walking beam carriers with millimetric scales for quick size change over, set on 3" centers with 2-1/2" high lugs, 80" long fixed bucket product in feed, with 2" long x 1-1/2" high x 6" deep buckets, 60" long manual product load area blank carton magazine, 2 suction cup reciprocating pic n place, no product / no carton and single head product ram. Control panel has swing arm touch pad controller with read out, flip up interlock safety guarding and mounted on base frame with leveling legs.

8′ Long x 2" Wide Product In Feed Conveyor Optional at additional cost

OAD: 108" L x 72" W x 72" H

Get a Free Quote Call: 630-629-9900

Bosch Cartoner Auto Horiz. Tuck (Auto) CUK 3060

  • Manufacturer: Bosch
  • Model Number: CUK 3060
  • Frain Number: 5G0711

Bosch Model CUK 3060, continuous motion, stainless steel, horizontal tuck, cartoner rated from 40 to 240 cartons per minute – depending on materials and application. Carton size range: 60mm to 120mm in Length; 15mm to 85mm in Width; 75 mm to 120mm in Depth. Equipped with a 72" long product infeed conveyor with guide rails, disk to star wheel product indexing system, container knock down, adjustable bucket conveyor, 28" long blank carton magazine, 3-head rotary vacuum pick and place, 3-chain carrier conveyor with 4" high lugs set on 6" centers, barrel cam loading section, and 28" long dual side belt compression discharge. Additionally features interlocking Lexan safety guarding, quick change Seco gauges, A/B PLC, and an A/B Panel View. Mounted on a stainless steel frame with height adjustable legs.

Optional Rontech prefolded leaflet feeder available at additional cost .

OAD: 288" L x 72" W x 88" H

Get a Free Quote Call: 630-629-9900

Bosch Cartoner Auto Horiz. Tuck (Auto) CAR T5

  • Manufacturer: Bosch
  • Model Number: CAR T5
  • Frain Number: 5G0710

Automatic, stainless steel, intermittent motion, horizontal tuck, cartoner rated from 30 to 100 cartons per minute – depending on materials and application. Cartoner size range: 20mm to 95mm in Length; 16mm to 70mm in Width; 60mm to 205mm in Depth. Equipped with an 84" long product infeed conveyor with ajustable guide rails, 24" long blank carton magazine, 2-cup vacuum reciprocating pick and place, 4-chain adjustable carrier chain with 3" high lugs set on 5" centers, right angle product to carton mechanical pusher, flap open gates during product load, top carton hold-down rail, and 28" long dule side compression belt discharge. Additionally features interlocking Lexan safety guarding, quick change Seco guages, status bar, Siemens PLC, and a swing arm touch panel operator interface. Mounted on a stainless steel frame with height adjustable legs.

Optional leaflet feeder and ink stamp coder available at additional cost.

OAD: 138" L x 68" W x 88" H

Get a Free Quote Call: 630-629-9900

Marchesini Cartoner Auto Horiz. Tuck (Auto) BA300GL

  • Manufacturer: Marchesini
  • Model Number: BA300GL
  • Frain Number: 5E9753

Automatic, continuous motion horizontal cartoner, capable of speeds from 120 to 300 cpm – speeds depending on materials and application. Carton size range: 25mm to 100mm in length; 13mm to 70mm in width; 78mm to 200mm in depth. Equipped with adjustable bucket in feed, three chain lug system set on 5" centers, rotary carton feeder, barrel cam product loader and tuck closure system. Additional features, card feeders, extended carton magazine and Siko gauges.
Mounted on casters.

OAD: 174" L x 74" W x 66" H

Options available at additional cost:
Emboss coder and Blister feeder.
