Incline cleated belt feeders are designed feed bulk solid items such as caps or parts. Incline cleated belt feeders are designed with an inclined conveyor belt with cleats which conveys the product up to the conveyor to a pre-determine discharge height. Bulk solid product is contained within the hopper of the incline cleated belt feeder. As the cleats pass through an opening in the bottom of the hopper, product falls between the cleats and is carried up the conveyor frame by the cleated conveyor belt. The cleated conveyor belt wraps around the conveyor frame at the top of the incline cleated belt feeder at which point the product held between the lugs drops from the top of the inclined cleated feeder due to gravity. Incline cleated belt feeders are often used to feed sorting equipment such as sorting bowls.
Hexcore stainless steel, inclined cleated feed conveyor with pounds of product per hour – depending on materials and application. Equipped with 34" long x 41" wide x 18" deep stainless steel product hopper with 24" Wide x 130" Long, neoprene belt, incline cleated belt conveyor has 32" high infeed with 2" high cleats set on 12½" centers and 77" discharge height with top mounted ½ Hp motor drive. Mounted on a (4) leg stainless steel frame
OAD: 135" L x 54" W x 84" H
MRM Elgin, stainless steel incline cleated belt feeder with amount of product per hour – depending on materials an application. Equipped with 30½" wide x 36" long x 22" deep (14 ft³) stainless steel product hopper, 13" wide belt conveyor with 3/16" high cleats set on 3-3/16" centers, 77" discharge height with 2¼" wide chute and 77" ground clearance. Powered by .89 hp motor drive. Mounted on stainless steel base frame.
OAD: 49" L x 32" W x 104" H
Kalish, Model SDR1, automatic stainless steel water fall style cap elevator / feeder and sorter. Rated from 50 to 300 caps per minute – depending on materials and application. Capable of handling screw, snap or childproof caps (with proper change parts). Equipped with a 34" wide x 21" long x 15" deep (5 ft³) cap hopper, 10½" wide x 60" long cleated cap conveyor belt with ¼" high cleats on 3" centers, 40" long adjustable discharge chute with 37" discharge height. Mounted on a stainless steel base frame with casters.
OAD: 50"L x 45"W x 71"H
Span Tech, inclined cleated conveyor. Equipped with an 18" infeed, 10" wide Intralox style conveyor belt with 2" high cleats set on 5" centers. Conveyor has a 32" long bottom horizontal run, 180" long incline, 32" long top horizontal run and a 180" discharge. Powered by a ¾ hp motor drive with leveling legs.
OAD: 160"L x 26"W x 192"H
Friesen’s, stainless steel, inclined cleated conveyor. Equipped with a 16½ – 20½" infeed range, 32" wide flat top Intralox style conveyor belt with 2" high cleats set on 16" centers. Conveyor has a 60" long bottom horizontal run, 68" long incline, 20" long top horizontal run and a 61" – 65" discharge range. (3) under conveyor spray bars each with (8) nozzels supplied by ¾" NPT fitting. Powered by a ½ hp motor drive with leveling legs.
OAD: 133"L x 51"W x 69"H
Inline Filling Solutions, automatic stainless steel water fall style cap elevator / feeder and sorter. Rated from 50 to 300 caps per minute – depending on materials and application. Capable of handling screw, snap or childproof caps (with proper change parts). Equipped with a 12" wide x 64" long cleated cap conveyor belt with ½" high cleats on 7" centers, 26" long x 12" wide x 24" deep stainless steel bulk product hopper and a 77" discharge height. Powered by a ½ hp drive with variable speed control. Mounted on a stainless steel base with leveling pads.
OAD: 42"L x 36"W x 92"H
Kalish, Model SDR2, automatic stainless steel water fall style cap elevator / feeder and sorter. Rated from 50 to 300 caps per minute – depending on materials and application. Capable of handling screw, snap or childproof caps (with proper change parts). Equipped with a 10½" wide x 55" long cleated cap conveyor belt with ¼" high cleats on 6" centers, 21" long x 33" wide x 16" deep (approx 5 ft³) stainless steel bulk product hopper, 16" long adjustable cap size discharge chute. Elevator on height adjustable stand with a 61" to 72" discharge range. Mounted on a stainless steel base frame with casters.
OAD: 53" L x 44" W x 78" H
Inclined cleated conveyor, stainless steel. Equipped with 21" infeed height, 18" wide conveyor belt with 3" high x 18" wide cleats set on 8" centers. Conveyor has 53" long bottom horizontal run, 48" long incline, 29" long top horizontal run and a 51" discharge height. Powered by a top mounted ¾ hp motor drive and mounted on a (4) leg stainless steel base frame with casters.
OAD: 120"L x 40"W x 55"H
Sidel, automatic stainless steel water fall style cap elevator / feeder and sorter. Rated from 50 to 300 caps per minute – depending on materials and application. Capable of handling screw, snap or childproof caps (with proper change parts). Equipped with a 15" wide x 72" long cleated cap conveyor belt with ½" high cleats on 3" centers, 33" long x 51" wide x 14" deep (approx 12 ft³) stainless steel bulk product hopper, 13" long discharge chute with 80" discharge height and E-stop. Mounted on a stainless steel base frame with leveling pads.
OAD: 48" L x 56" W x 98" H
Kofab, 15" Wide x 188" Long, stainless steel incline cleated belt conveyor. Equipped with a 29" high in feed, 2" high cleats set on 16" centers, 8" high collapsible guide rails for quick cleaning. Powered by a 1hp drive with a 99" high discharge. Mounted on stainless steel legs with leveling pads.
OAD: 192" L x 28" W x 110" H
CLI Model S005, automatic, stainless steel, water fall style, cap elevator / feeder rated from 50 to 300 caps per minute – depending on materials and application. Cap size range: 3/4" to 3" Diameter; to 1/4" thick and capable of handling screw, snap or childproof caps (with proper change parts). Equipped with 11" wide x 82" long cleated cap conveyor belt with 1/4" high cleats on 4-1/2" centers, lexan cover, 34" long x 28" wide x 38" deep stainless steel bulk product hopper with lexan flip top cover, 32" long discharge chute with 64" discharge height. Mounted stainless steel base frame with height adjustable legs.
OAD: 59" L x 57" W x 92" H
Stainless Specialists, 29¾" wide x 230" long, inclined cleated conveyor. Equipped with a 20" infeed height, 29¾" wide white plastic conveyor belt with 3" high x 26" wide cleats set on 4" centers. Conveyor has a 230" long incline and a 125" discharge height. Mounted on a (6) leg stainless steel base frame.
OAD: 235"L x 45"W x 125"H
