Vacuum Machines

Matsui Feeder Vacuum

• Manufacturer: Matsui
• Model Number:
• Frain Number: 5B2134

316 Stainless Steel Portable Transfer Feeder Has Cone Bottom And Measures 3’H X 4’D. Has 8" Dia Removable Clamp, (1) 1-3/4" Dia And (2) 1/2" Dia Side Bottom Outlets, 3-1/2" From Floor. Top Inlets Measure (1) 1-3/4" Dia, 2-1/4" Dia, 7-1/4" Dia And 18" Dia With Lift Off Cover. Tank Has (3) Kuroda Hi Rotor Pneumatic Air Motors And Air Panel Control. Low Pulse dense phase air conveying.

Pneuveyor Intl LTD Feeder Vacuum 106-8-36URAI-5

• Manufacturer: Pneuveyor Intl LTD
• Model Number: 106-8-36URAI-5
• Frain Number: 5F1883

(3) section, pneumatic, vacuum exhaust, transfer conveying system rated to 120cfm each 360cfm total – depending on material and application. Equipped with Pneuveyor Systems International conveying system package each has 5 Hp motor drive, vacuum exhaust system with volumes up to 120cfm each and vacuum guages to 30 Hg, blower package with silencer and bolt down cover, safety guards and all 3 sections mounted on heavy duty common base frame. Also with (2) 15 cu ft stainless steel transfer hopper with bolt down cover, level detectors and pneumatic butterfly discharge valves and side mounts. Last used in peanut transfer conveyor system to suck product from 2" diameter line.

OAD: 108" L x 72" W x 62" H (3) Conveying Sections
48" L x 46" W x 55" H Hopper Sections

Matsui Feeder Vacuum

• Manufacturer: Matsui
• Model Number:
• Frain Number: 5B2133

316 Stainless Steel Portable Transfer Feeder Has Cone Bottom And Measures 3’H X 4’D. Has 8" Dia Removable Clamp, (1) 1-3/4" Dia And (2) 1/2" Dia Side Bottom Outlets, 3-1/2" From Floor. Top Inlets Measure (1) 1-3/4" Dia, 2-1/4" Dia, 7-1/4" Dia And 18" Dia With Lift Off Cover. Tank Has (3) Kuroda Hi Rotor Pneumatic Air Motors And Air Panel Control. Low Pulse dense phase air conveying.

O/A Dimen: 64"L X 46"W X 52"

Matsui Feeder Vacuum SFD-400

• Manufacturer: Matsui
• Model Number: SFD-400
• Frain Number: 5G2767

316 Stainless Steel Portable Transfer Feeder Has Cone Bottom And Measures 3’H X 4’D. Has 8" Dia Removable Clamp, (1) 1-3/4" Dia And (2) 1/2" Dia Side Bottom Outlets, 3-1/2" From Floor. Top Inlets Measure (1) 1-3/4" Dia, 2-1/4" Dia, 7-1/4" Dia And 18" Dia With Lift Off Cover. Tank Has (3) Kuroda Hi Rotor Pneumatic Air Motors And Air Panel Control. Low Pulse dense phase air conveying.

O/A Dimen: 64"L X 46"W X 52"

Matsui Feeder Vacuum SFD-400

• Manufacturer: Matsui
• Model Number: SFD-400
• Frain Number: 5G2766

316 Stainless Steel Portable Transfer Feeder Has Cone Bottom And Measures 3’H X 4’D. Has 8" Dia Removable Clamp, (1) 1-3/4" Dia And (2) 1/2" Dia Side Bottom Outlets, 3-1/2" From Floor. Top Inlets Measure (1) 1-3/4" Dia, 2-1/4" Dia, 7-1/4" Dia And 18" Dia With Lift Off Cover. Tank Has (3) Kuroda Hi Rotor Pneumatic Air Motors And Air Panel Control. Low Pulse dense phase air conveying.

O/A Dimen: 64"L X 46"W X 52"

MAC/Sentinel Feeder Vacuum 10T/HR

• Manufacturer: MAC/Sentinel
• Model Number: 10T/HR
• Frain Number: 5D6378

Bulk powder vacuum transport system rated to move product at 20,000 lbs per hour – depending on materials and application. Equipped with vacuum recieving tank rated .75 psig @ 400F minimum and 1.25 psig @ 400F maximum with (2) 6" ID ports and 50 HP vacuum blower assy with heat exchanger to cool product lines. Vacuum tank has 10" ID flanged bolt-down discharge to rotary valve which transports product into Eriez magnetic filtration system with 10" ID product inlet & (2) 6" OD product outlets. From Eriez unit, product is fed to 48" dia. Sweco 12 mesh sifter. Sifter sends product to hopper with rotary valve. 75 HP pressure blower equipped with heat exchanger to cool product line sends product to desired location. Allen Bradley SLC5/03 PLC w/ touch screen display. Units mounted on mild steel frames for stability. Last used to transport sugar from rail car to storage tanks.

OAD: 88"(L) x 82"(W) x 267"(H)
