Incline cleated belt feeders are designed feed bulk solid items such as caps or parts. Incline cleated belt feeders are designed with an inclined conveyor belt with cleats which conveys the product up to the conveyor to a pre-determine discharge height. Bulk solid product is contained within the hopper of the incline cleated belt feeder. As the cleats pass through an opening in the bottom of the hopper, product falls between the cleats and is carried up the conveyor frame by the cleated conveyor belt. The cleated conveyor belt wraps around the conveyor frame at the top of the incline cleated belt feeder at which point the product held between the lugs drops from the top of the inclined cleated feeder due to gravity. Incline cleated belt feeders are often used to feed sorting equipment such as sorting bowls.

Contact Us

Incline/Cleated Equipment In Stock

Pneumatic Feeder Incline/Cleated 8000

  • Manufacturer: Pneumatic
  • Model Number: 8000
  • Frain Number: 5H4449

Pneumatic Scale, stainless steel incline cleated belt feeder. Equipped with a 36" wide x 32" long x 20" deep (10 ft³) stainless steel product hopper, 8" wide x 96" long belt conveyor with 2" high cleats set on 6" centers and is powered by ½ hp motor drive. Mounted on a height adjustable stand with a discharge range of 110" to 120"

OAD: 65"L x 37"W x 134"H

Get a Free Quote Call: 630-629-9900

The Platinum Packaging Group Feeder Incline/Cleated A71721

Platinum Packaging Group, Model A71721, servo driven stainless steel inclined cleated conveyor. Equipped with a 6" wide x 92" long food grade belt with 2" high cleats set on 6" centers. 48" long horizontal run has a 36" charge height. 44" long incline section has a discharge height of 60". Control panel with push button start / stop controls and touch screen HMI. Mounted on a stainless steel frame with casters.

OAD: 100"L x 23"W x 60"H

Get a Free Quote Call: 630-629-9900

Feeder Incline/Cleated

  • Model Number:
  • Frain Number: 5E0600

Dual lane feeder equipped with 4-1/2"L x 9-1/2"W x 14"H cleats, and 192"L x 12"W conveyor belt, two 10"L x 10"W separate discharge ports 10"H which both discharge a S/S rails.

OAD: 48"L x 156"W x 162"H

Get a Free Quote Call: 630-629-9900

Feeder Incline/Cleated

  • Model Number:
  • Frain Number: 5E0602

Stainless steel, incline cleated belt feeder. Equipped with 316" long x 16" wide neoprene belt conveyor, with 13" wide x 4" high cleats on 12" centers. Horizontal floor run of 56" to a 211" vertical lift to a overhead horizontal top run of 48" and 230" discharge height.

OAD: 112" L x 48" W x 235" H

Get a Free Quote Call: 630-629-9900

Feeder Incline/Cleated

  • Model Number:
  • Frain Number: 5H4442

Stainless steel, Z style bucket elevator. Number of lbs of product per hour – depending on materials and application. Equipped with white flexlink belt with inside dimensions of 11" long x 3" wide x 1" deep, set on 6" centers, has 60" long horizontal floor run with a 28" in-feed height to 126" vertical lift with a 24" wide frame, to 36" overhead horizontal top run and a 165" discharge height. Powered by a 1 Hp side mounted motor drive with on/off switch. Mounted on stainless steel base frame.

OAD: 127" L x 40" W x 192" H

Get a Free Quote Call: 630-629-9900

Dynamic Conveyor Corporation Feeder Incline/Cleated CLN3239

Dynamic Conveyor, Model Dyna Clean CLN3239, inclined cleated conveyor. Equipped with a 17" infeed, 12" wide blue conveyor belt with 2½" high cleats set on 10" centers. Conveyor has a 36" long bottom horizontal run, 96" long incline, 140" long top horizontal run and a 125" discharge.

OAD: 200"L x 27"W x 128"H

Get a Free Quote Call: 630-629-9900

Magnuson Feeder Incline/Cleated 21CH48

  • Manufacturer: Magnuson
  • Model Number: 21CH48
  • Frain Number: 5F4031

Stainless steel, bulk feeding system. Equipped with a 8 ft³ product hopper, twenty 48" long x 2" wide shuffling flights feeding into an eight lane indexing discharge system with twenty 48" long x 2" wide shuffling flights and variable speed controls. Mounted on height adjustable legs.

OAD: 76" L x 76" W x42" H

Get a Free Quote Call: 630-629-9900

Magnuson Feeder Incline/Cleated 21CH48

  • Manufacturer: Magnuson
  • Model Number: 21CH48
  • Frain Number: 5F4030

Stainless steel, bulk feeding system. Equipped with a 8 ft³ product hopper, twenty 48" long x 2" wide shuffling flights feeding into an eight lane indexing discharge system with twenty 48" long x 2" wide shuffling flights and variable speed controls. Mounted on height adjustable legs.

OAD: 76" L x 76" W x 42" H

Get a Free Quote Call: 630-629-9900

Dorner Feeder Incline/Cleated 3C24040806C0421

  • Manufacturer: Dorner
  • Model Number: 3C24040806C0421
  • Frain Number: 5F0235

Incline cleated 192"L x 24"W neoprene conveyor equipped with cleat dimensions of 2-1/4"L x 21-1/2"W x 4-1/4"H and a discharge chute at 4"L x 17"W with a in feed height of 20" and a discharge height of 62". Also features with Lexan guarding, pull cable E-stop, adjustable casters, adjustable screw legs and slight angle adjustments.
Total horizontal travel: 189"
(Initial horizontal travel of 40", horizontal travel of incline portion of 72", horizontal travel of top portion of 77")

OAD: 192"L x 40"W x 90"H

Get a Free Quote Call: 630-629-9900

Feeder Incline/Cleated 77" DISCH

  • Model Number: 77" DISCH
  • Frain Number: 5H4300

Hexcore stainless steel, inclined cleated feed conveyor with pounds of product per hour – depending on materials and application. Equipped with 34" long x 41" wide x 18" deep stainless steel product hopper with 24" Wide x 130" Long, neoprene belt, incline cleated belt conveyor has 32" high infeed with 2" high cleats set on 12½" centers and 77" discharge height with top mounted ½ Hp motor drive. Mounted on a (4) leg stainless steel frame

OAD: 135" L x 54" W x 84" H

Get a Free Quote Call: 630-629-9900

MRM Elgin Feeder Incline/Cleated 77" DISCH

  • Manufacturer: MRM Elgin
  • Model Number: 77" DISCH
  • Frain Number: 5H3924

MRM Elgin, stainless steel incline cleated belt feeder with amount of product per hour – depending on materials an application. Equipped with 30½" wide x 36" long x 22" deep (14 ft³) stainless steel product hopper, 13" wide belt conveyor with 3/16" high cleats set on 3-3/16" centers, 77" discharge height with 2¼" wide chute and 77" ground clearance. Powered by .89 hp motor drive. Mounted on stainless steel base frame.

OAD: 49" L x 32" W x 104" H

Get a Free Quote Call: 630-629-9900

Feeder Incline/Cleated

  • Model Number:
  • Frain Number: 5D9328

Stainless steel, inline cleated feeder with hopper. Equipped with 20 cu ft hopper, 14" wide cleated conveyor, 47" discharge, 10 by 1-1/2" cleates on 14 centers. Mounted on stainless steel frame wtih casters.

OAD: 130"L x 43"W x 52"H
