Vertical Tuck Machines

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: R40660

Jones Model CMV5, semi-automatic, continuous motion, vertical load, tuck cartoner. Carton size range: 1-1/4" to 4-1/4" in Length; 1" to 4-1/4" in Width; 2-1/2" to 8" in Depth. Equipped with 30" blank carton magazine, vacuum reciprocating carton pic-n-place, 5" centers, 5′ long loading area on each side of machine, top & bottom belt style tuck flap closure system and safety guarding. Speed dependent on materials, application, machine configuration and operator dexterity.

OAD: 185" L x 68" W x 65" H

Jones Cartoner Semi Vertical Tuck CMV-6

• Manufacturer: Jones
• Model Number: CMV-6
• Frain Number: R40651

Jones, model CMV, semi-automatic, continuous motion, vertical, tuck cartoner. Rated up to 120 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4¼" in Length; ¾" to 4¼" in Width; 2½" to 9" in Depth. Equipped with 3 chains with adjustable lugs set on 5" centers, 30" long carton magazine, reciprocating carton pick-n-place, 11" long x 4½" wide bottom compression belt, (2) 175" long product load zones, 11′ long x 4½" wide top compression belt, 58" long x 4½" wide discharge conveyor with a discharge height of 32".

OAD: 308" L x 62" W x 80" H

Emboss coder available for additional cost

Tishma Technologies Cartoner Semi Vertical Tuck TT-50

• Manufacturer: Tishma Technologies
• Model Number: TT-50
• Frain Number: R39960

Tishma Technologies, Model TT-50, semi-automatic, vertical, hand load cartoner. Rated from 25 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application. Equipped with 48" long (2) chain automatic blank carton magazine, (2) head rotary pic-n-place, fixed buckets set on 7½" centers, 60" long hand load area and 8½" wide x 55" long discharge conveyor. Control panel has AB controller with touch screen HMI. Mounted on heavy duty frame with interlock safety guarding.

OAD: 190"L x 83"W x 110"H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5J3710

Jones, Model IMV5, Semi-automatic, vertical, tuck, cartoner. Rated from 10 to 45 cartoners per minute – depending on materials, applicationand operator dexterity. Carton size range: 1" to 4" in length, ¾" to 2¾" in width, 1¾" to 7" in depth. Equipped with 2-chains with 5" centers, 4¼" long lugs, 26" long vibratory blank magazine, 4-cup reciprocating vacuum blank pick-off, (2) 48" long load station and cam driven right angle carton discharge. Control panel with AB controller and touch screen HMI.
Mounted on heavy duty frame with leveling legs.

OAD: 136"L x 64"W x 70"H

Jones Vertical Semi-Automatic Vertical Tuck Cartoner

• Manufacturer: Jones
• Model Number:
• Frain Number: R35520

Jones, Model IMV5, Semi-automatic, intermittent motion, vertical tuck cartoner. Carton size range: 1″ to 4-1/4″ in Length; 3/4″ to 4-1/4″ in Width; 2-1/2″ to 8″ in Depth. Equipped with (2) chains set on 5″ centers, with 1-1/2″ lugs, 40″ loading area, carton magazine, reciprocating pick-n-place, operator hand load area each side, major and minor flap closers and tuckers, right angle carton discharge and interlocked guarding. Controls feature AB PLC and touch screen. Speed dependent on materials, application, and machine configuration.

OAD: 135″ L x 60″ W x 65″ H

Tisma Cartoner Semi Vertical Tuck TC50E used cartoners

• Manufacturer: Tisma
• Model Number: TC50E
• Frain Number: R22181

Tisma Model TC50E, semi automatic vertical cartoner rated from 60 to 150 cartons per minute – speeds depending on materials and application. Machine is on 7-1/2" centers with carton size range of: (length) 1" – 6"; (width) 1/2" – 3"; (Depth) 2 1/2" to 8". Equipped with powder carton magazine, 2 head rotary feeder, graduated scale adjustments, 4′ 6" load area on each side of carousel, E- Stops, E-trac AC inverter, Piab vacuum system and interlocked guarding.

OAD: 150" (L) x 50" (H) x 52" (H)

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5E0147

Jones IMV5, Semi-automatic, intermittent motion, vertical tuck cartoner rated from 10 to 45 cartons per minute – speeds depending on materials and application. Cartons size range: 1" to 4-1/4" in Length; 3/4" – 4-1/4" in Width; 2-1/2" to 8" in Depth. Equipped with a 2-chain drive set on 5" centers, 3" lugs, 24" carton magazine, 42" of product load area on each side on machine, E-stop, integrated vacuum pump and interlocking barrier guarding. Mounted on height adjustable legs.

OAD: 127"L x 56"W x 66"H

Tisma Cartoner Semi Vertical Tuck TC50DE

• Manufacturer: Tisma
• Model Number: TC50DE
• Frain Number: 5G7620

Tisma, Model TC-50 DE, semi automatic, vertical hand load cartoner. Rated from up to 140 cartons per minute – depending on materials, application and operator dexterity. Single chain unit set on 5" centers. Carton specifications: 1" – 3½" (length) x ½" – 3" (width) x 2½" – 8" (depth) Equipped with a 48" long (2) chain powered blank carton magazine, (4) head rotary suction cup pick n place, fixed product pockets and 66" long hand load area on each side. Control panel has an AB PLC with touch screen HMI. Mounted on welded tubular base frame with interlock safety guarding.

Coder Available at Addition Cost

OAD: 187"L x 74"W x 96"H

Jones Cartoner Semi Vertical Tuck IMV5 Semi automatic intermittent motion vertical, reverse tuck cartoner capable of speeds up to 60 cartons per minute

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5D2866

Jones Model IMV5, Semi automatic intermittent motion vertical, reverse tuck cartoner rated from 10 to 45 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4" in Length x 3/4" to 2-3/4" in Width x 2-1/8" to 7" in Depth. Equipped with reciprocating pick and place carton feeder, polycarbonate lugs, set on 5” centers with 4′ product hand load area each side and bolt-on lugs. Control panel with start and e-stop push buttons. Mounted on heavy duty frame. Machine is currently set for reverse tuck cartons.

OAD: 132” L x 60” W x 58” H

Jones Cartoner Semi Vertical Tuck IMV5 Semi automatic intermittent motion vertical cartoner capable of speeds up to 60 cartons per minute

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: 5D2649

Jones IMV5, Semi automatic, intermittent motion vertical cartoner rated from 10 to 45 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4" in Length x 3/4" to 2 3/4" in Width x 2 1/8" to 7" in Depth. Machine is currently set for reverse tuck cartons and set on 5” centers. Equipped with: bottle loader, automatic pick and place carton feeder, polycarbonate lugs, 8′ long product load area (4′ on each side). Mounted on heavy duty frame with casters for mobility.

Optional prefolded leaflet feeder and coder are available for additional cost.

OAD: 134” L x 45” W x 75” H

Jones Cartoner Semi Vertical Tuck IMV

• Manufacturer: Jones
• Model Number: IMV
• Frain Number: 5J2450

Jones Model IMV, Semi automatic, intermittent motion, vertical tuck cartoner rated from 10 to 45 cartons per minute – depending on materials, application and operator dexteritry. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2½" to 7" in Depth. Equipped with (2) chain system set on 5" centers, with 22" long blank carton magazine, recipicating suction cup pic-n-place, 36" long load area each side, major flap tuckers and minor flap closers and self contained vacuum system. Control panel has start and e-stop push button controls. Mounted on heavy duty frame with casters.

OAD: 115" L x 61" W x 54" H

Jones Cartoner Semi Vertical Tuck IMV

• Manufacturer: Jones
• Model Number: IMV
• Frain Number: 5J2070

Jones, Model IMV5, Semi-automatic, intermittent motion, vertical tuck cartoner. Rated up to 45 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2½" to 7" in Depth. Equipped with (2) chains fixed set on 5" centers with 48" long operator hand load area each side, major and minor flap closers and tuckers. Control panel has start, stop, e-stop push button controls. Mounted on heavy duty frame with safety door guarding.

OAD: 136" L x 48" W x 64" H
