New England Capper 4 Head (Capper) NERCCE-2004-S
Back to All EquipmentNew England Model NERCCE, 4 head, stainless steel, rotary chuck capper and Model NES 36 cap feeder and bowl sorter with speeds – depending on number of heads, container size and configuration. Cap size range: 15mm to 70mm, container size range: 2" to 5" in diameter; 4" to14" in height with proper change parts. Equipped with 44" long x 2-1/4" wide product conveyor with Urethane coated container handling surfaces for gentle handling of containers and is constructed of non marring HDPE (change part per application). 24" rotary turret with 4 servo driven pneumatic chuck capper heads set on 15" centers and collet pull pins for quick release / change over adaptable to a wide variety of caps / containers and has electronic torque control for consistent applied torque of +/- 1.5 in per lb. Control panel with A/B controller with panel view and speed controllers, interlock safety guarding. Mounted on stainless steel base frame. NES 36 stainless steel cap feeder and sorter has 30" long x 27" wide x 26" deep cap hopper and 55" long x 10" wide flexlink conveyor belt with 3-1/2′ high cleats on 10" centers and 36" OD stainless steel sorting bowl.
OAD: 63" L x 48" W x 87" H Capper
56" L x 42" W x 89" H Feeder
