There are many different names that are used to describe particle size reduction: milling, grinding, granulating, comminuting, etc. Milling systems can size reduce wet or dry powders. Their are variable speed drives that permit low speed screening and high speed impacting with one milling system. A typical milling system consists of an inlet chamber with a rotor screen and an outlet. The particle size depends upon the speed of the rotor, rotor type, screen hole size and the feed rate of the product. High shear granulation turns powders into dense granules for tableting or coating. Powders are added to a mixing bowl. A large impeller spins the powders into a vortex. A chopper tool shears the granules and removes the air. The granulated product is dried in the mixing bowl or fluid bed dryer.
Fitzmill, Model D6A, Compact, enclosed GMP sanitary design, 316 stainless steel construction hammer mill, with pounds of product per hour – depending on materials and application. Equipped with 15" long x 15" wide x 9½" deep stainless steel product feed hopper with safety grid and Servolift metering system, for either loss-in-weight or gain-in-weight feeding and can handle both powders and granules, vari speed 3" OD feed auger, enclosed process chamber with (16) fixed stainless steel knife / impact blades and 13” long x 5” wide product discharge with 36” floor clearance. Remote control panel has speed adjust dials and start, stop buttons for mill and feed screw with feed screw rpm and machine amp readouts with e-stops. Mounted on heavy duty frame with locking casters.
OAD: 64" L x 52" W x 62" H
Fitzmill, Model D6A, Compact, enclosed GMP sanitary design, 316 stainless steel construction, hammer mill, pounds of product per hour – depending on materials and application. Equipped with 15" long x 15" wide x 9½" deep stainless steel product feed hopper with 10¼" diameter charge port, safety grid, stainless steel vari speed metering 3" diameter feed auger, enclosed process chamber with (16) fixed stainless steel knife / impact blades and 13” long x 5” wide product discharge with 36” floor clearance. Remote control panel has speed adjust dials and start, stop buttons for mill and feed screw with feed screw rpm and machine amp readouts with e-stops. Mounted on frames with locking casters.
Fitzmill Model DAS06, Stainless steel, particle reduction hammer mill with pounds of product per hour – depending on materials and application. Equipped with 12" long x 12" wide x 9" deep product hopper with safety grid, 4" OD x 18" long single auger feed screw powered by ¼ Hp motor drive with variable speed gearbox, (16) fixed, reversible stainless steel knife / impact blades and has 15" long x 6" wide product discharge port with safety grid and 36" floor clearence. Control panel has mill and feed screw start, stop push buttons. Mounted on (4) leg stainless steel frame with locking casters. Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
OAD: 53"L x 42"W x 66"H
Fitzmill, Model FASO12, Stainless steel hammer mill with pounds of product per hour – depending on materials and application. Equipped with 14" wide x 14" long x 42" deep hopper with 28" x 21½" charge and (2) feed augers, (24) fixed stepped impact blades powered by 25 Hp motor drive and has 6" ID / 6½" OD bottom discharge with 8" ground clearance. Mounted on (4) leg stainless steel platform style frame.
OAD: 70" L x 60" W x 82" H
Fitzmill, Model D6A, 316 Stainless steel, comminutor mill with production rates per hour – depending on materials, application and operator dexterity. Equipped with 20" wide x 26" long x 4" deep feed pan, 10" wide x 6" high feed throat, 12” long x 6” wide blade chamber and (16) fixed knife / impact blades powered by 5 hp drive. 12” long x 6" wide product discharge with 38” floor clearance. Mounted (4) leg stainless steel frame with casters. Used to grind, de-lump, pulverize and process wet / dry products.
OAD: 42" L x 54" W x 68" H
Fitzmill, Model D6A, 316 Stainless steel, comminutor mill with production rates per hour – depending on materials, application and operator dexterity. Equipped with 21" wide x 28" long x 4" deep feed pan, 12" wide x 6" high feed throat, 13” long x 6” wide blade chamber and (16) fixed knife / impact blades powered by 5 Hp motor drive. 13” long x 6" wide product discharge with 41” floor clearance. Mounted (4) leg stainless steel frame with casters. Used to grind, de-lump, pulverize and process wet / dry products.
OAD: 50" L x 45" W x 75" H
Fitzmill, Model D6A, Compact, enclosed GMP sanitary design, 316 stainless steel construction, pharmacutical hammer mill, with pounds of product per hour – depending on materials and application. Enclosed process chamber with (16) fixed stainless steel knife / impact blades and 5½” long x 13½” wide product discharge. Remote control panel has speed adjust dials and start, stop buttons for mill and feed screw with feed screw rpm and machine amp readouts with e-stops. Mounted on stainless steel frame.
OAD: 50"L x 51"W x 30"H – Mill 37"L x 40"W x 73"H – Controls
Fitzmill, Model D6A, compact, on-wall design, 316 SS construction, hammer mill with production rates per hour – depending on materials and application. Equipped with 12" long x 12" wide x 16" deep stainless steel product feed hopper 3" OD stainless steel vari speed metering feed screw to enclosed process chamber with (16) fixed stainless steel knife / impact blades and 5½" long x 13" wide product discharge port with 31" ground clearance. The in-wall and on-wall configurations of the VFS-D6A are designed to contain the drive motors in a separate room or technical area. Control panel has Mill and VFS start/stop push button controls.Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
OAD: 42"L x 51"W x 61"H – Mill 22"L x 34"W x 50"H – Controls
Fitzmill, Model DASO6, stainless steel hammer mill with production rates per hour – depending on materials, application and machine configuration. Equipped with 23" long x 13" wide x 10"H deep hopper, 5" diameter feed throat and (16) swing knife / knife blades powered by 7½ Hp motor drive. Product discharge port is 16” long x 5½” wide with 39” floor clearance. Mounted on (4) leg frame with casters.
OAD: 42"L x 36"W x 69"H
Fitzpatrick Model IR520, Stainless steel, medium volume, roller compactor chilsonator, with on board M5A Fitzmill hammer mill rated up to 150 kg of product per hour – depending on materials, application, machine configuration and environment being run in. 316 stainless steel construction. (2) screw feed design has 13" long x 9" wide x 10" deep ID stainless steel product hopper and rotary product assit to 3" OD x 12" long horizontal screw that eliminates vacuum dearation to 2" OD x 18" long vertical pre-compression screw that compresses product for more uniformity prior to feeding into the 5cm x 20cm or 2" wide x 8" OD groved product compaction rollers with a roller force of 26 KN/CM and roller gaps of 1mm to 6mm, powered by 5 Hp motor drive with noise level rating of 75 DB and has Fitzmill M5A hammer mill intergrated at discharge. Mounted on (4) leg frames with locking casters. Control panel with AB controller and touch screen HMI.
OAD: 35" L x 45" W x 85" H Chilsonator 45" L x 28" W x 63" H Control Cabinet
Fitzmill Model DAS06, 316 SS, hammer mill with pounds of product per hour – depending on materials and application. Equipped with 12" long x 12" wide x 10" deep hopper, 3" diameter feed auger. Stainless steel screw feed and safety guarding with (16) fixed stainless steel reversible knife / impact blades with 6" long x 14" wide product discharge with safety grid and 30" floor clearence. Control panel has estop push button control. Mounted on (4) leg stainless steel frame with locking casters. Used for precision grinding and controlled particle size reduction in pharmaceutical processing and other sanitary industries.
OAD: 50"L x 57"W x 70"H – Mill 44"L x 28"W x 62"H – Controls
Fitzmill, Model D6, 316 Stainless steel, comminutor mill with production rates per hour – depending on materials, application and operator dexterity. Equipped with 20" wide x 30" long x 5" deep feed pan, 6" wide x 8" high feed throat, 6” long x 10” wide chamber and (16) swing knife / impact blades powered by 7½ Hp motor drive. 9½” long x 5½" wide product discharge with 28” floor clearance. Mounted (4) leg mild steel base frame with casters. Used to grind, de-lump, pulverize and process wet / dry products.
OAD: 30" L x 48" W x 56" H
