Vertical Tuck Machines

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: 5J5970

Jones, model CMV, semi-automatic, continuous motion, vertical, tuck cartoner rated up top 120 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4¼" in Length; ¾" to 4¼" in Width; 2½" to 9" in Depth. Equipped with 3 chains with adjustable lugs set on 5" centers, 30" long carton magazine, reciprocating carton pick-n-place, 11" long x 4½" wide bottom compression belt, (2) 105" long product load zones, 11" long x 4½" wide top compression belt, 56" long x 4½" wide discharge conveyor with a discharge height of 32".

OAD: 252" L x 69" W x 80" H

Emboss coder available for additional cost

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: 5J5170

Jones, model CMV5, semi automatic, continuous motion, vertical, tuck cartoner with number of cartons per minute – dependanting on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4¼" in Length; ¾" to 4½" in Width; 2½" to 8" in Depth. Equipped with adjustable chsind set on 5" centers, 30" long carton magazine, reciprocating carton pick-n-place, 108" long product load area each side of machine with 4½" wide discharge conveyor.

OAD: 246" L x 73" W x 77" H

Jones Cartoner Semi Vertical Tuck CMV-8

• Manufacturer: Jones
• Model Number: CMV-8
• Frain Number: 5J5600

Jones, model CMV, semi-automatic, continuous motion, vertical, tuck cartoner rated between 45 to 80 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 2" to 7¼" in Length; 1" to 4¼" in Width; 3" to 9" in Depth. Equipped with 3 chains with adjustable lugs set on 8" centers, 30" long carton magazine, reciprocating carton pick-n-place, 11" long x 4½" wide bottom compression roller, (2) 120" long product load zones, 11′ long x 4½" wide top compression roller, 56" long x 4½" wide discharge conveyor with a discharge height of 32".

OAD: 249" L x 69" W x 70" H

Jones Cartoner Semi Vertical Tuck CMV-4

• Manufacturer: Jones
• Model Number: CMV-4
• Frain Number: R40600

Jones, model CMV 4, semi-automatic, continuous motion, vertical, tuck cartoner rated up top 120 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 5¼" in Length; ¾" to 4¼" in Width; 2½" to 8" in Depth. Equipped with single chain with fixed product buckets set on 6" centers, 74" long carton magazine, reciprocating carton pick-n-place, (2) 95" long product load zones, 34" long x 10" wide discharge conveyor with a discharge height of 35".

OAD: 236" L x 136" W x 82" H

Jones Cartoner Semi Vertical Tuck CMV-6

• Manufacturer: Jones
• Model Number: CMV-6
• Frain Number: R40650

Jones, model CMV, semi-automatic, continuous motion, vertical, tuck cartoner. Rated up top 120 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 5¼" in Length; ¾" to 4¼" in Width; 2½" to 9" in Depth. Equipped with 3 chains with adjustable lugs set on 6" centers, 30" long carton magazine, reciprocating carton pick-n-place, 11" long x 4½" wide bottom compression belt, (2) 105" long product load zones, 11′ long x 4½" wide top compression belt, 58" long x 4½" wide discharge conveyor with a discharge height of 32".

OAD: 224" L x 68" W x 81" H

Emboss coder available for additional cost

Bivans Cartoner Semi Vertical Tuck 74

• Manufacturer: Bivans
• Model Number: 74
• Frain Number: R40750

Bivans, Model 74, semi-automatic, continuous motion, vartiable speed, vertical tuck cartoner. Rated from 20 to120 cpm – depending on materials, application, operator dexterity and machine configuration. Carton size range: (7/8)" – 5" in Length; ¾" – 3½" in width; 2¼" – 10" in Depth. Equipped with a 24" long magazine, vacuum pick & place, 6" centers, 44" long load area on each side, 3" wide x 36" long discharge belt conveyor and lexan guarding. Control panel with push button start / stop / jog, run / jog switch, vaccuum on / off switch and variable speed control dial. Mounted on heavy duty base frame with casters and leveling pads.

OAD: 148"L x 65"W x 87"H

Jones Cartoner Semi Vertical Tuck IMV

• Manufacturer: Jones
• Model Number: IMV
• Frain Number: R40675

Jones, Model IMV5, Semi-automatic, intermittent motion, vertical tuck cartoner. Rated up to 45 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2½" to 7" in Depth. Equipped with (2) chains fixed set on 5" centers with 48" long operator hand load area each side, major and minor flap closers and tuckers. Control panel has start, stop, e-stop push button controls. Mounted on heavy duty frame with safety door guarding.

OAD: 136" L x 48" W x 64" H

Jones Cartoner Semi Vertical Tuck IMV5

• Manufacturer: Jones
• Model Number: IMV5
• Frain Number: R40680

Jones, Model IMV5, Semi-automatic, vertical, tuck, cartoner. Rated from 10 to 45 cartoners per minute – depending on materials, applicationand operator dexterity. Carton size range: 1" to 4" in length, ¾" to 2¾" in width, 1¾" to 7" in depth. Equipped with 2-chains with 5" centers, 4¼" long lugs, 26" long vibratory blank magazine, 4-cup reciprocating vacuum blank pick-off, (2) 48" long load station and cam driven right angle carton discharge. Control panel with AB controller and touch screen HMI.
Mounted on heavy duty frame with leveling legs.

OAD: 136"L x 64"W x 70"H

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: R40671

Jones, Model CMV5, semi automatic, continous motion, vertical tuck cartoner,rated from 40 to 120 cartons per minute – depending on materials, application and operator dexterity. Carton size range: 1" to 4¼" in Length x ¾" to 4" in Width x 2½" to 9" in Depth. Equipped with (3) chains adjustable set on 5" centers, 30" long blank carton magazine with recipicating suction cup pick-n-place, 120" long operator load areas (one each side of machine) and 45" long x 5" wide carton discharge conveyor. Control panel has Moeller PLC, on / off switches and push button start / stop. Mounted on heavy duty base frame.

OAD: 235"L x 70"W x 68"H

Jones Cartoner Semi Vertical Tuck CMV5

• Manufacturer: Jones
• Model Number: CMV5
• Frain Number: R40672

Jones, Model CMV5, Semi automatic, continuous motion, vertical, tuck cartoner, rated from 40 to 120 cartons per minute – depending on materials and application and operator dexterity. Carton size range: 1" to 4¼" in Length x ¾" to 4½" in Width x 2½" to 9" in Depth. Equipped with (3) chains adjustable set on 5" centers, with 29" long blank carton magazine with vibratory feeder and carton pusher, reciprocating single head suction cup pick-n-place, 96" long load area each side with major and minor flap closers and tuckers with 96" long x 4" wide discharge conveyor belt. Control panel has PLS controller with control power and carton feed on / off switches, start, stop push buttons with e-stop. Mounted on heavy duty frame with safety guarding and statis light.

OAD: 211" L x 58" W x 79" H

Jones Cartoner Semi Vertical Tuck IMV

• Manufacturer: Jones
• Model Number: IMV
• Frain Number: R40673

Jones, Model IMV 5, Semi-automatic, intermittent motion, vertical tuck cartoner. Rated from 10 to 45 cartons per minute – depending on materials, application, machine configuration and operator dexterity. Carton size range: 1" to 4" in Length; ¾" to 2¾" in Width; 2-1/8" to 7" in Depth. Equipped with (2) chains fixed, set on 5" centers, with 26" long blank carton magazine, reciprocating pic-n-place, 48" long operator load area each side, minor flap tuckers and major flap closers. Control panel has start / stop push button controls. Mounted on heavy duty frame with safety door guarding.

OAD: 136"L x 45"W x 65"H

Tisma Cartoner Semi Vertical Tuck TC50E

• Manufacturer: Tisma
• Model Number: TC50E
• Frain Number: R40674

Tisma, Model TC-50E, Semi-automatic, vertical, hand load cartoner rated from 25 to 150 cartons per minute – depending on materials, application and operator dexterity. Carton size range: per application. Equipped with (2) chain fixed, set on 5" centers, with 33" long (2) chain automatic blank carton magazine (2) head rotary pic-n-place, 48" long hand load area with operator e-stop each side. Control panel has start, jog and e-stop push buttons with statis light bar. Mounted on heavy duty frame with interlock safety guarding.

OAD: 168" L x 60" W x 85" H
