Case Erector Machines

Used Case Erector Equipment

case erectorFrain Industries has hundreds of case erector machines and other end of line packaging equipment in stock and ready to set up for your application.  Frain carries many types of case erectors depending on your specific application, case size, speed, and line integration requirements.  Case erector machines and equipment are available in fully automatic or semi-automatic configuration and with many footprints depending on you container size.  Additionally different case erectors can handle a wide range of container types including:

  • RSC (regular slotted case)
  • AFM (all flaps meet)
  • HSC (half slotted case)
  • HSC with display
  • Five panel RSC or HSC with or without display
  • RSC bottom with folding flap
  • Interlocking cases
  • Self locking cases
  • Tablock cases
  • Bliss cases

A case erector is a machine designed to erect a case from flat folded, pre-scored, case blank made from corrugated containerboard or other material.  A case erector takes one case blank from a magazine and forms or erects the case through the uses of mechanical devices, pneumatic devices, or a combination of both depending on the design of the machine.  Case erectors can be designed to seal the bottom of the case using either tape or glue, or not to seal the bottom of the case at all.  Cases can be erected with either the case opening facing up or the case opening facing to the side.  Special case erectors can be designed to erect bliss boxes, insert partitions into a box or case, or to erect a case and insert a bag into the case for a bag-in-box application (see Bag-in-box).  Bliss boxes are created with a solid piece of containerboard that is formed to create the front, back, and bottom of the box.  A bliss box case erector then inserts two additional pieces of containerboard to form the sides of the case.  The two addition pieces are sealed to flaps on the main portion of the case using hot melt glue.

Case erectors are widely used in many industries for automated drop loading and hand packing applications. They are used to form cases, trays, and boxes for the food, beverage, nutraceutical, personal care and household care industries.  Frain’s case erector are highly customizable and can be integrated seamlessly into any production line.

In addition to standard case erectors Frain industries carries the following:

  • Partition Inserters – Designed to automatically place partitions of the type used to separate bottles and jars into open cases.  Flat partitions are are erected form a stack and expanded using mandrels.  The expanded partitions are then inserted into the awaiting case.
  • Bag Inserters – Designed to open, insert, and cuff plastic bags from roll stock into a wide variety of corrugated containers.

Contact Frain Industries to discuss your application requirements with one of our engineers.  We can design a complete solution depending on your case erecting requirements.

Frain carries case erectors from many OEM’s including: ABC, Arpac, Bemis, Cermex, Combi, Delkor, Durable, Dyna Pak, Eagle Packaging Machinery, Elliott, Fallas, Hartness, K&R, Lantech, Little David, Loveshaw, Marq, McDowell, Moen, New Way, OK International, Padlocker, Pearson, Serpa Packaging, Sig, SWF, Thiele, WE Plemons, Wayne, Wepackit, Wexxar and others.

Contact Us

Case Erector Equipment In Stock

Dyna Pak Case Erector COP3

  • Manufacturer: Dyna Pak
  • Model Number: COP3
  • Frain Number: 5F2616

Dyna Pack Model C0P3, Case erector and positioner with number of cases per minute – depending on materials and application. Equipped with 52" Long x 34" Wide two chain powered flat blank case magazine, three pivoting pneumatic arms with suction cups and three pneumatic minor, major flap closers. The combined operation will pull, erect, close flaps and position empty case to advance to case packing operation. Start/stop push bottons and e-stop.

OAD: 136" L x 48" W x 81" H

Get a Free Quote Call: 630-629-9900

ABC Case Erector Glue 500

  • Manufacturer: ABC
  • Model Number: 500
  • Frain Number: 5F4100

ABC Model 500, automatic, continuous motion, hot glue, case erector and bottom sealer, rated from 20 to 55 cases per minute – speeds depending on materials and application. Knock down case size: 14-1/4" to 29-3/4" in Length; 12-1/4" to 26" in Width. Equipped with a 32" long blank case magazine, reciprocating vacuum pick and place, lugged chain carrier system set on 32" centers, top squaring conveyor, minor and major flap closers, two compressing rams, hot melt glue system, and interlocking Lexan guarding.

OAD: 180" L x 84" W x 68" H

Get a Free Quote Call: 630-629-9900

Marq Case Erector Tape HPE315-4/RH/DL

  • Manufacturer: Marq
  • Model Number: HPE315-4/RH/DL
  • Frain Number: 5F4110

Marq Model HPE3154RH, automatic, case erector, bottom taper rated from 5 to 10 cases per minute – speeds depending on materials and application. Case size range: 6" to 27" in Length; 5.25" to 18.5" in Width; 3.5" to 18" in Height. Knockdown Range: 12" to 43" in Length; 10.5" to 33" in Width Equipped with a continuous feed magazine, top / bottom vacuum suction cup pick off, lugged chain case conveyor, minor and major flap closers, top squaring device, 3" tape head, PLC with touch pad controller, and safety guarding. Mounted on height adjustable legs and casters.

OAD: 91" L x 82" W x 72" H

Get a Free Quote Call: 630-629-9900

Padlocker Case Erector Glue CF209XL

  • Manufacturer: Padlocker
  • Model Number: CF209XL
  • Frain Number: 5B9041

Padlocker Model CF 209 XL case erector bottom sealer hot melt is capable of doing from 5 to 15 cases per minute – speeds depending on materials and application. Case size range of: (12" to 30" L) x (12" to 24"W) x (10" to 20"H). Equipped with case magazine, AB PLC, Nordson hot melt system and Lexan guarding.

OAD: 14′ L x 6′ W x 6′ H

Get a Free Quote Call: 630-629-9900

Padlocker Case Erector Glue CF209XL

  • Manufacturer: Padlocker
  • Model Number: CF209XL
  • Frain Number: 5B9121

Padlocker Model CF 209 XL case erector bottom sealer hot melt capable of doing from 5 to 15 cases per minute – speeds depending on materials and application. Has case size range: 15" to 32" long, 10" to 22" wide, 8" to 24" height. Unit equipped with bottom sheet hopper, XL frame, Allen Bradley slc 500 controller, (2) emergency stops heavy duty caster for mobility, lexan gaurding and nordson ct-7 time interval controls. Magazine measures 49"w x 54"l.

OAD: 14’l x 6-1/2’w x 6-1/2’h

Get a Free Quote Call: 630-629-9900

Durable Case Erector Tape TGA200IR

  • Manufacturer: Durable
  • Model Number: TGA200IR
  • Frain Number: 5H2945

Durable, Model TGA200IR, automatic, left to right case erector and bottom taper. Rated from 5 to 20 cases per minute – depending on materials, application and machine configuration. Case size range: 7" to 20" in Length; 6" to 16" in Width; 4" to 16" in Depth. Equipped with 36" long blank magazine, suction cup case pick and place, 2" wide pressure sensitive tape head, and dual 58" long x 2½" wide side belt asset conveyors. Control panel with start, stop, e-stop controls. Mounted on (4) leg base frame.

OAD: 115" L x 84" W x 81" H

Get a Free Quote Call: 630-629-9900

Wexxar Case Erector Tape WF2T

  • Manufacturer: Wexxar
  • Model Number: WF2T
  • Frain Number: 5G9929

Wexxar, Model WF-2T, automatic, inline case erector and bottom tape sealer. Rated from 5 to 25 cases per minute – depending materials and application. Case size range: 7" to 24" in Length; 5" to 17" in Width; 5" to 12" in Height. Equipped with 72" long powered blank case magazine, recipicating pin and dome case forming plates, minor and major flap closers, hand crank height and width adjustable, case pusher bar, 2" Dekka tape head and 32" long dual side belt discharge section. Control panel has A/B PLC with push button controls for jog, start, stop and e-stop. Includes statis light bar and safety guarding. Mounted on (4) leg base frame with leveling legs.

OAD: 130"L x 68"W x 84"H

Get a Free Quote Call: 630-629-9900

Durable Case Erector Tape TGA200IQCL

  • Manufacturer: Durable
  • Model Number: TGA200IQCL
  • Frain Number: 5H2944

Durable, Model TGA200IQCL, automatic, right to left case erector and bottom taper. Rated from 5 to 20 cases per minute – depending on materials, application and machine configuration. Case size range: 7" to 20" in Length; 6" to 16" in Width; 4" to 16" in Depth. Equipped with 48" long blank magazine, suction cup case pick and place, 2" wide pressure sensitive tape head, and dual 58" long x 2½" wide side belt asset conveyors. Control panel with start, stop, e-stop controls. Mounted on (4) leg base frame.

OAD: 110" L x 110" W x 81" H

Get a Free Quote Call: 630-629-9900

Wexxar Case Erector Tape ABFT

  • Manufacturer: Wexxar
  • Model Number: ABFT
  • Frain Number: 5H2976

Wexxar, Model ABF-T, automatic, inline case erector and bottom tape sealer. Rated from 5 to 15 cases per minute – depending materials, application and machine configuration. Case size range: 8" to 22" in Length; 6" to 16" in Width; 4" to 19" in Height. Equipped with 48" long powered blank case magazine, recipicating pin and dome case forming plates, minor and major flap closers, hand crank height and width adjustable, case pusher bar, 2" tape head and 32" long dual side belt discharge section. Control panel has A/B PLC with push button controls for jog, start, stop and e-stop. Mounted on (4) leg base frame with leveling legs.

OAD: 146"L x 53"W x 90"H

Get a Free Quote Call: 630-629-9900

ABC Case Erector Glue 230HM

  • Manufacturer: ABC
  • Model Number: 230HM
  • Frain Number: 5H2942

ABC, Model 230HM, automatic, case erector, hot melt glue, bottom sealer. Rated from 5 to 30 cases per minute – depending on materials, application and machine configuration. Case size range: 7" to 22¾" in Length; 5¾" to 16" in Width; 3" to 15" in Height. Equipped with 60" long automatic blank case magazine, suction cup pick and place, lugged walking beam case in feed and suction cup case erector, lugged walking beam case transfer with Nordson hot melt glue system, major and minor flap closers and single ram arm compression section. Control panel has start / e-stop push buttons controls and vacuum on / off switch. Mounted on heavy duty base frame.

OAD: 187"L x 86"W x 75"H

Get a Free Quote Call: 630-629-9900

Pearson Case Erector Tape R23501

  • Manufacturer: Pearson
  • Model Number: R23501
  • Frain Number: 5H2941

Pearson, Model R23501, automatic, case erector and tape bottom sealer. Rated from 1 to 35 cases per minute – depending on materials, application and machine configuration. Case size range: 8¾" to 23½" in Length; 5" to 16" in Width, 8¼" to 21" in Depth. Equipped with 56" long x 18" wide (4) chain automatic blank case magazine, suction cup pic n place and case erecting squaring system, 75" long dual lugged chain conveyor, single top lugged chain with top hold down, top flap lifters and rear flap closers and plow and 3M Accuglide 2" tape sealer. Control panel has an AB controller with push button start / stop / jog. Mounted on heavy duty base frame with interlock safety guarding.

OAD: 206"L x 90"W x 94"H

Get a Free Quote Call: 630-629-9900

Pearson Case Erector Tape R23501

  • Manufacturer: Pearson
  • Model Number: R23501
  • Frain Number: 5H2940

Pearson, Model R23501, automatic, case erector and tape bottom sealer. Rated from 1 to 35 cases per minute – depending on materials, application and machine configuration. Case size range: 8¾" to 23½" in Length; 5" to 16" in Width, 8¼" to 21" in Depth. Equipped with 56" long x 18" wide (4) chain automatic blank case magazine, suction cup pic n place and case erecting squaring system, 75" long dual lugged chain conveyor, single top lugged chain with top hold down, top flap lifters and rear flap closers and plow and 3M Accuglide 2" tape sealer. Control panel has an AB controller with push button start / stop / jog. Mounted on heavy duty base frame with interlock safety guarding.

OAD: 206"L x 90"W x 94"H

Get a Free Quote Call: 630-629-9900
