Frain Industries has hundreds of case erector machines and other end of line packaging equipment in stock and ready to set up for your application. Â Frain carries many types of case erectors depending on your specific application, case size, speed, and line integration requirements. Â Case erector machines and equipment are available in fully automatic or semi-automatic configuration and with many footprints depending on you container size. Â Additionally different case erectors can handle a wide range of container types including:
A case erector is a machine designed to erect a case from flat folded, pre-scored, case blank made from corrugated containerboard or other material. A case erector takes one case blank from a magazine and forms or erects the case through the uses of mechanical devices, pneumatic devices, or a combination of both depending on the design of the machine. Case erectors can be designed to seal the bottom of the case using either tape or glue, or not to seal the bottom of the case at all. Cases can be erected with either the case opening facing up or the case opening facing to the side. Special case erectors can be designed to erect bliss boxes, insert partitions into a box or case, or to erect a case and insert a bag into the case for a bag-in-box application (see Bag-in-box). Bliss boxes are created with a solid piece of containerboard that is formed to create the front, back, and bottom of the box. A bliss box case erector then inserts two additional pieces of containerboard to form the sides of the case. The two addition pieces are sealed to flaps on the main portion of the case using hot melt glue.
Case erectors are widely used in many industries for automated drop loading and hand packing applications. They are used to form cases, trays, and boxes for the food, beverage, nutraceutical, personal care and household care industries. Â Frain’s case erector are highly customizable and can be integrated seamlessly into any production line.
In addition to standard case erectors Frain industries carries the following:
Contact Frain Industries to discuss your application requirements with one of our engineers. Â We can design a complete solution depending on your case erecting requirements.
Frain carries case erectors from many OEM’s including:Â ABC, Arpac, Bemis, Cermex, Combi, Delkor, Durable, Dyna Pak, Eagle Packaging Machinery, Elliott, Fallas, Hartness, K&R, Lantech, Little David, Loveshaw, Marq, McDowell, Moen, New Way, OK International, Padlocker, Pearson, Serpa Packaging, Sig, SWF, Thiele, WE Plemons, Wayne, Wepackit, Wexxar and others.
Pearson, Model CE35G, automatic, case erector and hot melt glue bottom sealer. Rated from 10 to 35 cases per minute – depending on materials, application and machine configuration. Case size range: 6" to 23½" in Length; 5" to 16" in Width, 3½" to 18½" in Depth. Equipped with 77" long (4) chain automatic blank case magazine, suction cup pic n place and case erecting squaring system with top hold down, hand crank height and width adjustable case feed section, top flap lifters and rear flap closers and plow and Nordson hot melt glue system. Control panel has AB controller with AB PanelView touch screen HMI and statis light bar. Mounted on heavy duty base frame with interlock safety guarding.
OAD: 225"L x 88"W x 90"H
Wexxar, Model WF30T, Automatic, in line case erector, bottom tape sealer. Rated from 5 to 30 cases per minute – depending on materials, application and machine configuration. Case size range: 7-1/4" to 18" in Length; 7-1/4" to 14" in Width; 6" to 15" in Height. Equipped with 72" long (2) belt powered blank case magazine, pin and dome case forming plates, minor and major flap closers, case pusher bar, 2" Dekka flip up tape head and 36" long x 3" wide dual side belt discharge section with 24" to 29" discharge height. Control panel has a PLC controller with panel view touch screen controls, digital dial indicator, start and e-stop push buttons with status light bar. Mounted on heavy duty frame with leveling legs and safety guarding.
OAD: 132" L x 60" W x 87" H
Wexxar, Model WF30T, Automatic, in line case erector, bottom tape sealer. Rated from 5 to 30 cases per minute – depending on materials, application and machine configuration. Case size range: 7-1/4" to 18" in Length; 7-1/4" to 14" in Width; 6" to 15" in Height. Equipped with 72" long (2) belt powered blank case magazine, pin and dome case forming plates, minor and major flap closers, case pusher bar, 2" Dekka flip up tape head and 36" long x 3" wide dual side belt discharge section with 24" to 29" discharge height. Control panel has a PLC controller with panel view touch screen controls, digital dial indicator, e-stop and status light bar. Mounted on heavy duty frame with leveling legs and safety guarding.
Pearson Model CE15T, Automatic case erector and bottom taper rated up to 15 cases per minute – depending on materials and application. Case size range: 7.5" to 24" in Length; 7.5" to 16" in Width; 3" to 18.5" in Height. Equipped with 80" long x 36" wide (4) chain automatic blank case magazine, (2) suction cup vacuum pic-n-place, bottom major and minor flap closers, 60" long x 3" wide side belt case assit and 2" bottom tape head with safety guarding and low profile discharge design. Control panel has A/B micrologix controller with A/B panel view and touch pad controls with readout has machine and cycle start stop with e-stop push buttons. Mounted on heavy duty frame.
OAD: 96" L x 80" W x 72" H
Pearson Model BI18, Automatic bag inserter with number on cases per minute – depending on materials and application. Erected case size range: 9.5" to 24" in Length; 9.5" to 17" in Width; 10" to 24" in Depth Open (top flaps open and bottom flaps closed). Poly bag specifcations: Maximum bag width of 26" and maximum bag length of 38.5". Equipped with opening carriage and vacuum cup assist, (4) corner cuffing rods and (1) bag inserting head, which Inserts pre-performed roll stock or gusseted bag stock into cases, covering all corners and cuffing the bag around the outer perimeter, with vacuum pump, safety guarding and e-stop. Control panel has A/B micrologix controller with A/B panel view and touch pad controls with readout has machine and cycle start stop with e-stop push buttons. Mounted on heavy duty frame.
OAD: 96" L x 76" W x 108" H
Wexxar, Model WF-30T, Automatic, in line case erector, bottom tape sealer. Rated from 5 to 30 cases per minute – depending on materials, application and machine configuration. Case size range: 6" to 18" in Length; 5" to 14" in Width; 6" to 15" in Height. Equipped with 72" long (2) belt powered blank case magazine, pin and dome case forming plates, minor and major flap closers, case pusher bar, 2" Dekka flip up tape head and 36" long x 3" wide dual side belt discharge section with 24" to 29" discharge height. Control panel has a PLC controller with panel view touch screen controls, digital dial indicator, e-stop and status light bar. Mounted on base frame with leveling legs and safety guarding.
Wexxar, Model WF-30T, Automatic, in line case erector, bottom tape sealer. Rated from 5 to 30 cases per minute – depending on materials, application and machine configuration. Case size range: 7-1/4" to 18" in Length; 7-1/4" to 14" in Width; 6" to 15" in Height. Equipped with 72" long (2) belt powered blank case magazine, pin and dome case forming plates, minor and major flap closers, case pusher bar, 2" Dekka flip up tape head and 36" long x 3" wide dual side belt discharge section with 24" to 29" discharge height. Control panel has a PLC controller with panel view touch screen controls, digital dial indicator, e-stop and status light bar. Mounted on heavy duty frame with leveling legs and safety guarding.
Pearson, Model CE35G, Automatic, case erector and hot melt glue bottom sealer. Rated from 10 to 35 cases per minute – depending on materials, application and machine configuration. Case size range: 6" to 23½" in Length; 5" to 16" in Width, 3½" to 18½" in Depth. Equipped with 77" long (4) chain automatic blank case magazine, suction cup pic n place and case erecting squaring system with top hold down, hand crank height and width adjustable case feed section, top flap lifters and rear flap closers and plow and Nordson hot melt glue system. Control panel has AB controller with AB PanelView touch screen HMI and statis light bar. Mounted on heavy duty frame with interlock safety guarding.
ABC, Model 330T, automatic, stainless steel, case erector, bottom sealer. Rated from 10 to 35 cases per minute – depending on materials, application and machine configuration. Case size range: 7" to 22" in Length; 5¾" to 16" in Width; 7" to 22" in Height. Equipped with 60" long automatic blank case magazine, suction cup pick and place, lugged walking beam case in feed and suction cup case erector, lugged walking beam case transfer with major and minor flap closers and 2" dekka tape head. Control panel has AB PLC with a touch screen HMI.
OAD: 213"L x 66"W x 74"H
Combi America Model 2EZHS, automatic, case erector, bottom hot melt glue sealer. Case size range: 8" to 24" in Length; 6" to 16" in Width; 5" to 18" in Height. Equipped with 57" long case magazine, (5) suction cup pic-n-place, minor and major flap closers, 48" long dual side belt case indexing, non-tool adjustable, vacuum system, Siko gauges, Nordson ProBlue hot melt glue system and interlock safety guarding. A/B controller with panel view, safety reset, start, stop, e-stop and status light bar. Mounted on casters and leveling legs. Speed dependant on materials, application and machine configuration.OAD: 105" L x 80" W x 77" H Magazine up 105" L x 137" W x 77" H Magazine down
ABC, Model 230, automatic, case erector, bottom tape sealer. Rated from 5 to 35 cases per minute – depending on materials, application and machine configuration. Case size range; 7" to 22" in Length; 5¾" to 16" in Width; 7" to 22" in Height. Knock down dimmensions: 12" to 38" in Length; 8" to 29¼" in Width both (RSC) and (HSC) cases. Equipped with 72" long (2) belt blank case magazine, suction cup pick and place, walking beam case transfer, 48" long x 2½" wide dual upper and lower case belt drive transports thru the 2" tape head. Control panel has start / e-stop push buttons controls with flip up, interlock safety guarding. Mounted on heavy duty frame with leveling legs.
OAD: 160" L x 60" W x 74" H Erector 72" L x 34" W x 34" H Magazine
Combi America Model 2EZHS, automatic, case erector, bottom taper. Case size range: 8" to 24" in Length x 6" to 16" in Width x 5" to 18" in Height. Equipped with 80" long blank case magazine, pic-n-place case erector, minor and major flap closers, dual side belt case transfer, 3" bottom tape head and interlock safety guarding. A/B panel view, E-Stop and statis light bar. Mounted on leveling legs. Speed dependent on materials, application and machine configuration.
OAD: 105" L x 80" W x 84" H Magazine up 105" L x 160" W x 75" H Magazine down
Combi America Model 2EZHS, automatic, case erector, bottom taper rated from 5 to 20 cases per minute – depending on materials, application and operator dexterity. Case size range: 8" to 24" in Length x 6" to 16" in Width x 5" to 18" in Height. Heavy duty welded steel construction. Equipped with easy load, 80" long automatic blank case magazine, (5) suction cup pic-n-place case erector, minor and major flap closers, 44" long x 3-1/4" wide dual side belt case indexing, 3" bottom tape head, hand crank no-tool adjustable, vacuum system and interlock safety guarding. Control panel has A/B controller with A/B panel view and safety reset, start, stop and e-stop controls with ethernet interface port and statis light bar. Mounted on height adjustable frame with leveling legs.
