Bucket elevator conveyors move dry product or solid product to a high level. The conveyor takes the product at a low level and carries it to a high level in a bucket. At the top of the conveyor, the bucket rotates over and dumps the product out. The bucket then travels down the back side of the frame to be filled again. A bucket elevator has two chains which carry the buckets. The buckets are closely spaced together allowing for a nearly continuous flow of product.
Nedco Ultralift bucket elevator. Equipped with 19" high infeed, (70) polycarbonate buckets (6-1/2" long, 12" wide, 3-1/2" deep) on 6" centers, 146" high discharge, 24" run, 122" rise, 30" top horizontal run, control panel with on/off switch, auto/off/manual switch and variable speed and stainless steel construction throughout. Mounted on (6) leveling legs.
OAD: 74"L x 40"W x 160"H
Whiz Lifter "Z" style bucket elevator, Number of lbs of product per hour – depending on materials and application. Product buckets with inside dimensions of 20" L x 9" W x 5" D. 24" Infeed, with 67" long horizontal floor (46" long workable fill area) to 166" vertical lift, overhead 60" long horizontal top run. 10" x 11" discharge funnel has 184" discharge height.
OAD: 150"L x 45"W x 208"H
Universal Industrial, Z style bucket elevator. Number of lbs of product per hour – depending on materials and application. Equipped with white plastic product buckets with inside dimensions of 5" long x 11¾" wide x 2¾" deep and has 45" long horizontal floor run with a 24" long load area and 22" feed height to 118" vertical lift with a 19" wide frame, to 32" overhead horizontal top run with 13" x 13" discharge funnel with a 109" discharge height and 7" frame clearance. Powered by a 1½ HP side mounted motor drive. Control panel with on / off switch and variable speed control. Mounted on heavy duty base frame.
OAD: 122"L x 30"W x 140"H
Stainless steel, Z style bucket elevator. Number of lbs of product per hour – depending on materials and application. Equipped with white flexlink belt with inside dimensions of 11" long x 3" wide x 2" deep, set on 6" centers, has 72" long horizontal floor run with a 17" in-feed height to 122" vertical lift with a 11½" wide frame, to 72" overhead horizontal top run and has 8" x 9½" discharge funnel with a 144" discharge height. Powered by a 1 Hp side mounted motor drive with on/off switch. Mounted on stainless steel frame.
OAD: 181" L x 41" W x 175" H
Meyer, Model PA45218S, Z style bucket elevator. Number of lbs of product per minute – depending on materials, application and machine configuration. Equipped with white plastic product buckets with inside dimensions of 18" long x 5" wide x 2-3/4" deep and has 79" long horizontal floor run with a 30" in feed height to 182" vertical lift with a 27" wide frame, to 80" overhead horizontal top run and has an open end 185" discharge height. Powered by a 1½ HP top mounted motor drive.
OAD: 240"L x 48"W x 212"H
"Z" Style bucket elevator. Horizontal floor run of 64"; 136" vertical lift; 29" horizontal top run; 142" discharge height. Buckets inside dimensions: 8" by 4-1/4" by 2-1/2" in Depth. Mounted on four leg base frame.
OAD: 119" L x 24" W x 150" H
"Z" scoop stype bucket elevator with production rates – dpending on materials and application. Equipped with 75 cleats with inside dimensions: 24" Long x 2 1/2" Wide x 4" Deep, a 2’6" high infeed, a horizontal floor run of 48" long with 11" delrin guiderails, to a 216" long vertical lift with 5" s/s guiderails, to a 36" long horizontal overhead run with 5" s/s guiderails, with a discharge height of 276" (23′). Mounted on a stainless steel frame.
OAD: 120" L x 53" W x 312" H
Z-style bucket elevator equipped with 6"L x 9"W x 2-1/2"D plastic buckets and a 132" load area. In feed height at 14" and product travels 132" before elevating 72"H then traveling 48" before discharging at 56"H through a 2-1/2" x 1-1/2" chute.
OAD: 208"L x 48"W x 92"H
Whiz Lifter, Model Z style bucket elevator. Equipped with 42" long x 32" wide x 16" deep product hopper with bottom vibratory feeder and 35" charge height. White plastic product buckets have inside dimensions of 10" long x 5½" wide x 3" deep and has 19" long horizontal floor run with 14" in feed height to 120" vertical lift with 17" wide frame, to 24" overhead horizontal top run and has 6" x 6" discharge funnel with 115" discharge height. Powered by a top mounted motor drive with a variable speed controller. Mounted on base frame with casters.
OAD: 88"L x 35"W x 134"H
Unitrak Corp, Model "S2" Tip Trak, Z style bucket elevator. Bucket speeds rated from 0 to 150 feet per minute. Equipped with plastic product buckets with inside dimensions of 10½" long x 4½" wide x 5" deep, 50" long horizontal floor run at 22" in feed height, 128" vertical lift, 50" overhead horizontal top run, 129" discharge height and a 1 Hp drive. Mounted on A-frame base with casters. Volume of product dependant on materials, application and machine configuration.
OAD: 177" L x 90" W x 157" H
"Z" style bucket elevator, has approx (96) white plastic product buckets, with inside dimensions of 12 in Length x 4-1/4" in Width x 2-1/2" in Depth and has a horizontal floor run of 75" long with approx 66" of workable fill area to a 156" vertical lift, to a overhead 52" horizontal top run with 131" discharge height and mounted on painted powder (4) leg base frame.
OAD: 129" L x 24" W x 156" H
Cidiesse Engineering, Model ETD 83, Z style bucket elevator. Number of lbs of product – depending on materials and application. Equipped with white plastic product buckets with inside dimensions of 11¾" long x 7¾" wide x 5½" deep and has a 70" long horizontal floor run with bucket drop product idexing, 37" in feed height to 98" vertical lift with a 22" wide frame, to 133" overhead horizontal top run and has a 42" x 16" discharge opening with a 100" discharge height. Powered by a 1 HP side mounted motor drive. Control cabinet with on/off switches and variable speed controller.
OAD: 225" L x 39" W x 125" H
