Stainless steel ribbon powder blenders or mixers have been the most widely used mixers for both dry powders and incorporating some liquids into a dry mixture. Stainless steel ribbon powder mixers can handle a wide variety of product and sizes for making good mixtures. Stainless steel ribbon powder mixers usually are the slowest type of mixers to achieve the required mixture but they do not generate high heat and can actually unmix materials if left in the mixing mode for too long a period. The materials of construction can be carbon steel with total dry mixes and non-corrosive materials to all stainless steel and other specialty steels for maintaining the integrity of the mixer.
Rietz, Model RS-28-K5406, 304 stainless steel dual trough ribbon blender with pounds of product per hour – depending on materials and application. Working Capacity: 60 ft³. Dual trough dimensions: 72" in Length; 56" in Width; 36" in Depth. Equipped with (3) lift up top safety grates, (6) steam injection ports, 2½" wide x (3/8)" thick stainless steel ribbons and has dual pneumatic discharge gates with 42" ground clearance. Powered by (2) 15 Hp chain to sprocket motor drives with safety guarding. Mounted on (4) leg base frame.
OAD: 102"L x 75"W x 85"H
Mueller, 50 ft³, double ribbon mixer with pounds of product per hour – depending on materials and application. 304 stainless steel contact parts. Inner mixing chamber dimensions of: 58" in Length; 41" in Width; 45" in Depth. Equipped with dual flip up cover and lift out safety grate, 3" OD mixing shaft with 1½" wide x (5/8)" thick (outer) and 2½" wide x (3/8)" thick (inner) stainless steel ribbons and (2) CIP spray balls. 4¾"OD / 3¾" ID Tri-Clamp discharge with 27" ground clearence. Mounted on (4) leg frame.
OAD: 96"L x 55"W x 80"H
75 ft³ (70 ft³ working capacity), 304 stainless steel double ribbon mixer with pound of product per hour – depending on materials and application. Inner mixing chamber dimensions: 96" in Length; 38" in Width; 40" in Depth. Equipped with dual flip up covers, 12" OD charge port, 4½" OD mixing shaft with 1¼" wide x (3/8)" thick (outer) and 2" wide x ¼" thick (inner) stainless steel ribbons. 9" OD center bottom discharge has manual slide valve with 43" floor clearence and 20 Hp motor drive. Mounted on (4) leg base frame.
OAD: 155" L x 46" W x 95" H
5 Cuft, 304 S/S, fully jacketed, single shaft double ribbon blender (37 gallon working capacity) and a 6 cubic foot (45 gallon) overall capacity. Has side liquid injection w/ 5 ports. Chamber measures 38"(W) x 17"(L) x 18"D). Jacket working pressure 80 psi @ 324 Deg. F. Shell working pressure is Atmosphere @ 324 Deg. F. Jacket has (2) 1" side inlet/outlet ports, (2) 1" bottom inlet/outlet ports, and (2) 3/16" side pressure relief ports. Equipped with dual hinged dust tight lid with a 7/8" center vent, sanitary stuffing box, continuous ribbon agitator with the inner spokes measuring 3/16”(thick) x 1 ”(high), outer spoke 3/8” (thick) x 1"(high), 3" dust tight slide gate center bottom discharge at 35” from the ground. Allen Bradley start/stop controls and safety switches. Mounted on casters. National Board # 1677(OAD: 65"(L) x 24"(W) x 52"(H).
Aaron, 25 ft³ (23 ft³ working capacity), 304 stainless steel double ribbon mixer with pound of product per hour – depending on materials and application. Inner mixing chamber dimensions: 66" in Length; 26" in Width; 30" in Depth. Equipped 4" OD mixing shaft with ¾" wide x ¼" thick (outer) and 2" wide x ¼ thick (inner) stainless steel ribbons. 6" OD center bottom discharge with manual slide valve and 45" floor clearence. Mounted on (6) leg base frame.
OAD: 143" L x 32" W x 88" H
Mepaco, Model 170, 304 stainless steel, jacketed, dual trough ribbon blender, rated from 0 to150 pounds of product per batch and pounds per hour – depending on materials application and machine configuration. Capacity: 2½ ft³ total (2 ft³ working). Dual trough dimensions: 25" in Length; 22" in Width; 15" in Depth each trough. Equipped with lift up top cover and safety grate, dual pneumatic gate discharges with 30" ground clearance and powered by (2) 1 Hp motor drives with mechanical variable speed. Control panel has start / jog / stop and switches for mix / unload / reverse and open / close for both discharge doors. Mounted on heavy duty base frame with casters.
Top Ports:(1) 1" NPT(1) ¼" NPT
Jacket Ports:(4) 1" NPT
MAWP: 100 psi @ 338°FMDMT: -20°F @ 115 psiNat’l Brd: 10711
OAD: 46"L x 40"W x 51"H
Scott Equipment Model TB1610, stainless steel, continuous ribbon / paddle mixer with pounds of product per hour – depending on materials, application and machine configuration. Chamber dimensions: 120" in Length; 24" ID. Equipped with dual 14" long x 10" wide top product feed ports and dual 34" long x 8" wide flip-up bolt down top access covers and 92" long bolt down flip open bottom access doors. Has inner 6" long x 3" wide paddles and 1" wide x 1/2" thick single ribbon on 1" OD spokes set on 4" OD shaft. 20" long x 11" wide flanged end bottom discharge with (8) 1/4" bolts holes set on 6" centers with 19" floor clearence. 7-1/2 Hp belt to motor drive with safety guarding. Mounted on stainless steel frame. This style of mixer uses both the paddle agitator design and simultaneously giving end-to-end mixing action of the ribbon design.
OAD: 160" L x 36" W x 54" H
J H Day, 16 ft³ workable, double ribbon mixer with 304 stainless steel contact parts. Inner mixing chamber dimensions: 60" in Length; 24" in Width; 26" in Depth. Equipped with flip up cover, 2" diameter mixing shaft with 1" wide x ¼" thick (outer) and 1¼" wide x (1/8)" thick (inner) stainless steel ribbons powered by a 5 hp drive. 3½" diameter center bottom discharge has manual slide gate with 54" ground clearence.
OAD: 92"L x 39"W x 85"H
Lowe, Model C-16, 20 ft³ (16 ft³ workable), double ribbon mixer with 304 stainless steel contact parts. Inner mixing chamber dimensions: 60" in Length; 24" in Width; 26" in Depth. Equipped with (3) section flip up cover, 12" diameter charge port with pneumatic butterfly valve, 12" diameter open vent, 2½" diameter motor shaft, 3" diameter mixing shaft with 1½" wide x ½" thick (outer) and 2" wide x ¼" thick (inner) stainless steel ribbons. 6" diameter center bottom discharge has pneumatic slide valve with 0" floor clearence. Powered by a 10 Hp motor and mounted on mild steel (4) leg base frame
OAD: 90" L x 55" W x 60" H
Ross 304 Stainless steel, double ribbon blender. Capacity: 25 ft³ Working; 30 ft³ Total. Trough dimesions: 60" in Length; 29" in Width; 33" in Depth. Blender rated for up to 50 lbs per cu. ft. Equipped with bag break station with lid and 4" High center bottom pneumatic slide gate discharge, start stop control package, and interlocking top covers. 80 Grit finish on the interior and exterior.
Feed Height (with stand) 113"Discharge Height (with stand) 78"
OAD: 96" L x 44" W x 143"H
304 S/S Double ribbon blender with 17 cu ft working capacity (19.5 cu ft full capacity). Chamber dimensions: 52" in Length; 24" in Width; 29" in Depth. Equipped with: flip top cover, 2" double ribbon shaft and center bottom 8" discharge with 42" floor clearance.
OAD 88" L x 48" W x 86" H
4 cuft. (30 gal), 304 S/S ribbon blender. Internal dimensions: 24"(L) x 18"(W) x 22"(D). Equipped with cover with safety switch, 2 3/8" diameter shaft, 1" wide ribbon, 6" ID slide gate discharge and variable speed. Mounted on casters.
OAD: 60"(L) x 36"(W) x 72"(H)
