Shrink bundlers are designed to wrap a single piece or bundle of product in heat shrinkable plastic film. Shrink bundlers are designed to form the plastic wrap around the product or bundle using two rolls or plastic film (with only one notable exception). Shrink bundlers create bundles or product that have open ends know as bulls-eyes on each side of the package. By using film that is much wider than the bundle on a shrink bundler, the size of the bulls-eye can be reduced. By using a film that is narrower than the bundle on a shrink bundler, the bundle of product is wrapped by a band of plastic.
Shrink bundlers take in product and pass the product bundle through a barrier of film that is created by heat sealing the film ends of two rolls of plastic film. As the bundle passes through the film barrier, the top roll of the film wraps around the top of the bundle and the bottom roll of the film wraps around the bottom of the bundle. After the container has passes the heat sealing station, the seal jaws on the shrink bundler come together again to seal the films together after the bundle and to separate the wrapped bundle from the remainder of the film. This action leaves a film barrier created by heat sealing the ends of the film together, which allows the next shrink bundle to pass through the film barrier. The shrink bundle then passes through a heat shrink tunnel to shrink the film around the bundle of product.
Arpac, Model 55GI-20CX, Inline, continuous motion, shrink bundler. Rated from 10 to 55 bundles per minute – depending on materials, application and machine configuration. Equipped with 13" wide x 25" long in feed conveyor, (2) 21" wide film roll holders with film splicing stations, film hoist, 21" wide walking beam seal jaws with 11" vertical travel and 13" wide x 38" long transfer conveyor to shrink tunnel. 50" long single zone shrink tunnel has 21” wide x 16" high total aperture, 70" long x 20½" wide product conveyor and cooling fan discharge. Control panel with AB controller, touch pad controls with readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty base frame.
OAD: 145"L x 52"W x 105"H
Great Lakes HVP41737, fully automatic shrink bundler and tunnel rated from 5 to 20 bundles per minute – depending on materials and application. Equipped with dual upper and lower film arbors, powered film feed, 36" wide x 24" long in feed conveyor, adjustable product guides. 36" wide hot wire cutoff seal, 24" long x 36" wide out feed conveyor, 60" long tunnel with 27" high x 44" wide aperture and fan cooled discharge. Able to accommodate 12" high product.
OAD: 246"L x 67" W x 83"H
Arpac, Model 55GI-20, Inline, continuous motion, shrink bundler. Rated from 10 to 55 bundles per minute – depending on materials, application and machine configuration. Equipped with 13" wide x 26" long in feed conveyor, (2) 21" wide film roll holders with film splicing stations, 21" wide walking beam seal jaws with 11" vertical travel and 14" wide x 36" long transfer conveyor to shrink tunnel. 70" long single zone shrink tunnel has 24” wide x 16" high total aperture, 90" long x 21" wide product conveyor and cooling fan on discharge. Control panel with A/B controller, touch pad controls with readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty base frame.
OAD: 170"L x 55"W x 78"H
Automatic, inline, registered shrink bundler. Equipped with indexing system, bottom film carriage, film registration, 36" long x 24" wide rotary arm wrap station, interlocking Lexan safety guarding and Allen Bradley Controllogix, with 10 inch HMI touch screen. Film width up to 24". Tunnel: Equipped with a 30" wide x 12" high aperture, 72" long dual zone heating chamber and 100" long x 28" wide conveyor.Speed dependant on materials, application and machine configuration.
OAD Wrapper : 124" L x 66" W x 70" HTunnel: 102" L x 72" W x 80" H
Arpac Model 10828, Automatic, right angle, shrink bundler rated 10 to 20 bundles per minute – depending on materials, application and machine configuration. Equipped with 10" wide x 60" long stainless steel powered roller infeed conveyor, product pusher, 29" wide seal jaw with 12" of vertical travel, top hold down and (2) 5" wide x 16" long transfer conveyors to shrink tunnel. Shrink Tunnel dimensions: 33" wide x 15" high aperture; 100" in Length Chamber. Equipped with 26" wide x 144" long mesh conveyor belt, top mounted center blower, rear cooling fan with (2) side compression rollers. Control panel has A/B PLC with variable temperature and speed controls with statis light. Mounted on heavy duty frame with casters.
OAD: 254" L x 56" W x 80" H
Arpac, Model 105-24 Inline, intermittent motion, shrink bundler and tunnel. Rated from 5 to 20 bundles per minute – depending on materials and application. Equipped with 22" wide x 70" long in feed conveyor, 24" wide film rolls, 25" wide seal jaws with 13" vertical travel, 22" wide x 22" long Intralox transfer conveyor to shrink tunnel. Single zone shrink tunnel has 24” wide x 15" high total aperture x 60" long with 90" long x 24" wide Intralox product conveyor. Control panel has touch pad controls and readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty base frame.
OAD: 190"L x 63"W x 84"H
Arpac, Model 105TW28, Inline, shrink bundler. Equipped with 20" wide x 70" long slip torque in feed conveyor, 28" wide hot knife cross seal with 12" vertical travel and 25¼" wide x 12" long transfer conveyor to shrink tunnel. 70" long shrink tunnel has 29” wide x 17" high total aperture, 110" long x 29" wide product conveyor and cooling fan on discharge. AB PLC and touch pad controls with readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty frame. Speed dependent on materials, application and machine configuration
OAD: 202"L x 72"W x 90"H
Arpac, Model 108-28 TW, right angle shrink bundler. Rated from 10 to 20 bundles per minute – depending on materials, application and machine configuration. Equipped with 10" wide x 40" long in feed conveyor, film hoist, 90° product pusher, 29" wide hot knife seal jaws with 10" vertical travel and bundle hold down tamp. 83" long single zone shrink tunnel has 30” wide x 16" high total aperture, 128" long x 29" wide product conveyor and cooling fan on discharge. Control panel with AB controller, touch pad controls with readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty base frame.
OAD: 223"L x 68"W x 121"H
Arpac, Model 55GI-20CX, Inline, continuous motion, shrink bundler. Rated from 10 to 55 bundles per minute – depending on materials, application and machine configuration. Equipped with 13" wide x 36" long in feed conveyor, (2) 21" wide film roll holders with film splicing stations, film hoist, 21" wide walking beam seal jaws with 11" vertical travel and 13" wide x 26" long transfer conveyor to shrink tunnel. 70" long single zone shrink tunnel has 21” wide x 16" high total aperture, 90" long x 20½" wide product conveyor, cooling fan and roller side compression on discharge. Control panel with AB controller, touch pad controls with readout, start / stop / e-stop / manual seal push button controls and digital temperature controls for seal bar and tunnel. Mounted on heavy duty base frame.
OAD: 167"L x 60"W x 105"H
Thiele, dual lane shrink bundler. Product: up to 8½". Film width: up to 15". Equipped with 90° / right angle infeed, dual pusher plates, dual 16" wide seal bars, dual 15" wide x 21" long transfer conveyors, stainless steel shrink tunnel with 15" high aperture and 48" long chamber. Stainless steel frame with interlocked safety guarding and leveling pads. AB PLC with PanelView. Speeds dependent on materials, application and machine configuration.
OAD: 180"L x 64"W x 96"H
Arpac, Model 115-36, Inline, shrink bundler. Equipped with 26¾" wide x 42" long in feed conveyor, 37" wide hot knife seal jaws with 12" vertical travel and 26¾" wide x 42" long transfer conveyor into shrink tunnel.Tunnel: 83" long tunnel has 37” wide x 15" high total aperture, 125" long x 37" wide conveyor, cooling fan and roller side compression on discharge. AB controller, touch pad and digital temperature controls for seal bar and tunnel. Speed dependant on materials, application and machine configuration.
OAD: 218"L x 65"W x 120"H
