PMC Model RC 6000, automatic, 6-head rotary, stainless steel, capper rated from 24 to 120 containers per minute – depending on materials and application. Container size up to 4-3/4" in Width; 8" in Height. Equipped with 120" long x 3-1/4" wide plastic delron product conveyor with worm screw to star wheel in feed / discharge, product grippers, 6 rotary air chuck capping heads set on 6" centers with no container / no cap. Control panel has A/B controller, with swing arm touch pad controls and read out with capper, sorter, conveyor, start, stop and jog controls with e-stop, misssing item detection on / off switch, safety guarding. Mounted on stainless steel base frame. Capable of appling screw caps, with individual torque adjustment on each spindle, snap-on caps and insertable plugs. with proper change parts.
OAD: 120" L x 48" W x 83" H
Consolidated Model D6F, automatic, 6 head rotary chuck capper rated from 24 to 180 containers per minute – depending on materials and application. Cap size: up to 100mm. Container Size: up to 5" in Diameter (with proper change parts). Equipped with cap hopper, disc cap sorter, feed chute with cap pick off . 96" long x 2-1/4" wide container conveyor with 32" long worm screw in feed to star wheel discharge, no container / no cap, rotary turret with (6) torque open chucks with turret safety guarding. mounted on heavy duty base frame.
OAD: 96" L x 48" W x 92" H
Consolidated Model D6-F, automatic, 6 head rotary chuck capper rated from 24 to 180 containers per minute – depending on materials and application. Cap size: up to 100mm. Container Size: up to 5" in Diameter both with proper change parts. Equipped with 150" long x 3¼" wide container conveyor with 24" long worm screw to star wheel container indexing, cap hopper, disc cap sorter, feed chute, cap pick off, no container / no cap, 16" OD rotary turret with safety guarding, double container grippers and (6) torque open chucks set on 8" centers. Controller has start, stop, e-stop push buttons with elevator and cap auto, off, manual control switches, counter and statis light bar Mounted on heavy duty base frame.
OAD: 150" L x 40" W x 91" H
Consoildated, 6 Head rotary chuck capper rated from 60 to 175 containers per minute – depending on materials and application. Cap size: up to 70mm / Container size: up to 5" diameter – with proper change parts. Equipped with 3" wide by 47" long cap conveyor, 3½" wide x 81" long container conveyor, star wheel in feed and discharge, container body clamps, (6) cap chucks, and interlocked safety guarding. Change parts required to accommodate size range of container and cap.
OAD: 92"L x 37"W x 75"H
Consolidated Model D6FA, automatic 6 head rotary chuck capper rated from 24 to 180 containers per minute – depending on materials and application. Cap size: up to 70mm and Container Size: up to 5" in Diameter (with proper change parts). Equipped with cap sorting feeding with feed chute, cap pick in place, 72" long container infeed conveyor with a 32" long timing screw, star wheel, container clamps, no container cap discharge chute, star wheel discharge, and a 36" long discharge conveyor.
OAD: 120" L x 52" W x 108" H
