Commercial cutter and slicer equipment is designed to cut, slice, dice, chop, process, peel, and strip cut various different products such as cheeses, meat, vegetables, fruits, breads, pastes. Cutter and slicer equipment covers a number of different types of machines that can be used in the size reduction of a variety of food products. The proper cutter and slicer for the application is based on the product that is to be cut, sliced, or processed, the type of cut, slice, or process needed for the application, and the volume of product that needs to be processed in a given amount of time. Commercial utter and slicer equipment utilize a variety of rotating, spinning, cross-cuting, shredding, and other types of blades and knives to properly process the product.
Urschel Model H, stainless steel USDA, dicer / slicer / cutter for a variety of food products with volumes per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 1" Slice Thickness, 3/4" to 1-3/4" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5-1/2" in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls and is mounted on stainless steel base frame. Change parts required for size changes. Currently set for
Urschel Model 1700 Comitrol, stainless steel, reduction mill for free flowing dry and semi-dry product with number of pounds of product per hour – depending on materials and application. Equipped with 12" ID x 12" Deep product hopper 17" OD x 17" milling chamber with (3) 3" dog leg style high speed rotating impeller and cutting head with vertical blades and 4-1/2" OD triclover product inlet and 3-1/2" triclover product discharge with 30 Hp motor drive. Control panel has push botton start, stop, auto and manual control switches. Mounted on stainless steel base frame. Operations include communiting, granulating, milling, slicing, liquifying, dispersing, and pureeing.Change parts required per application.OAD: 48" W x 33" L x 66" H
Gemac Model 2501 Hydraflaker, stainless steel, frozen block breaker rated from 1 to 3 blocks per minute – depending on materials and application. Block sizes up to 24" in Length: 24" in width; 10" in Height, down to 0 Deg F and can reduce product down to 1/4" thick in 18 to 30 seconds and 1/32" thick in 2 minutes plus (depending on product). Equipped with 30" wide x 69" long product feed table with 22" wide x 6-1/2" high hydraulic product ram to 28" long x 12" OD (8) blade rotary drum cutting assembly has flip up safety cover with interlock shut-off and 30" wide discharge chute with 28" floor clearence. Mounted on (4) leg base frame.
OAD: 92" L x 52" W x 55" H
Urschel, Model TRS2000, stainless steel slicer used for a variety of food products with number of pounds of product per hour – depending on materials and application. Equipped with 20" diameter cutting wheel, 96" long V-belt infeed with a 48" long load area and variable speed controls for both the belt and wheel. Ideally suited for elongated firm products to 4" diameter and 6" diameter for compressible leafy products. Mounted on stainless steel (4) leg base frame with casters. Capable of flat slices, crinkle slices and julienne cuts. Change parts required to accommodate specific cut configuration
OAD: 130"L x 36"W x 56"H
Urschel, Model Diversacut 2110, stainless steel, dicer, slicer, strip cutter with inclined feeder used for a variety of food products with number of pounds of product per hour – depending on materials and application. Equipped with 13" x 12" product charge and has swing open locking access door with safety interrupt switch, has crosscut and circular knifes and accepts product up to 10" in any dimension and 13" x 12" discharge chute with 22" floor clearence. Control panel has start, stop and e-stop push button controls with 5 Hp stainless steel motor drive. Mounted on stainless steel base frame. Also has stainless steel, Inclined cleated feeder and hopper with 96" long x 12" wide neophreme product belt with 2-1/4" high lugs set on 6" centers with 76" discharge height.
OAD: 65" L x 55" W x 75" H Urschel 92" L x 38" W x 76" H Inclined Feeder
All S/S dicer uniformly dices, strip cuts, and slices a wide variety of products at high production capacities, and accepts products up to 10" in any dimension. Types of cuts slices: flat & crinkle slices: 1/16 to 1" Strip cuts: flat and crinkle minimum/maximum flat strips 1/8 x 1/8" to 1 x 1" x length of product. Crinkle strips 9/32 x 9/32" length of product. Circular knife cuts: 1/8 to 3" Crosscut knife cuts: 1/8 to 1-1/2" Crosscut knife crinkle cuts: 9/32 to 5/8" Change parts required to accommodate size range.
OAD: 64"L x 64"W x 62"H
Stephan Model UMHC40E, 40-liter, stainless steel, steam jacketed, pilot plant, vacuum cooker, and cooler with pounds of product per hour – depending on materials, application and machine configuration. Bowl is rated for full vacuum and internal steam pressure rating of 55 psi. Jacket pressure rating of 29 psi. Maximum process temperature of 260° F. Equipped with flip up, bolt down cover, top mounted side scrape agitator, product funnel and vacuum gauge, direct steam injection, chopper timer, temperature probe, serrated blades, side bottom discharge and locking tilt discharge. Auxiliary pieces including vacuum system with vacuum pump, condensation tank, and hot / cold water connections. Control panel has product, water feed, jacket, vacuum, tank and condenser controls with thermostat steam temp and chopper timers. Mounted on a 102" long x 51" wide stainless steel platform. Designed for pilot plant operation and can be run manually, semi-automatic or with pre-determined programs from solid state controller and can produce a wide range of product procedures in one machine such as fine cutting, cooking, blending, emulsifying, de-aerating, sterilizing homogenizing and pasteurizing under vacuum pressure with heating and cooling
OAD: 102” L x 51” W x 76” H
Urschel Model M6, stainless steel, belt fed, dicer, shredder and strip cutter designed for meat products and is capable of production rates from 500 to 4,500 lbs. per hour – depending on materials, application and machine configuration. Capable of strip cuts from 3/16" to 3" and cross cuts from 1/8" to 4". Equipped with 32" x 9" load area on feed belt and adjustable feed roll allowing for positive product feed at all thicknesses from 3/8" to 1". Change parts required to accommodate size range.
OAD: 120"L x 35"W x 43"H
Urschel Model CCD, stainless steel, slicer, strip cutter, shredder and crinkle cutter used for a variety of different food products with production rates with volumes per hour – depending on materials, application and machine configuration. Flat Slices: 0.8mm to 12.7mm, Standard Crinkle: 3-1/3 to 5.7 waves per inch Depth of Crinkle: 2.0mm to 2.1mm, Thickness: .040mm to .285mm, V-Slices 4.7 to 8 waves per inch Depth of Crinkle: (4.7) 2.1mm, Thickness: 1.0mm to 2.5mm. Depth of Crinkle (8)1.3mm, Thickness: 1.0mm to 2.5mm. Also does Oval, Cresent Shreds and strip cuts (all with proper change parts). Equipped with centrifical type slicer utilizes rotating impeller to force the product to the side walls and thru (8) individual inter-changeable cutting heads that enable the processor to change the type of cuts in minutes and has inexpensive to replace, specially designed throw away knives. Accept products up to 3-1/2" in any dimension. Stainless steel feed hopper, discharge chute and start / stop push buttons controls. Mounted on push cart with casters
OAD: __" L x __" W x __" H
Urschel Model G, stainless steel USDA, dicer / slicer / cutter used for a variety of food products with volumes per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 5/8" Slice Thickness, 9/32" to 3" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5-1/2" in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls. Mounted on stainless steel base frame with casters. Change parts required for different size changes.
OAD: 64"L x 32"W x 60"H
Urschel, Model G, stainless steel dicer / slicer / cutter with inclined feeder used for a variety of food products with number of pounds of product per hour – depending on materials and application. Utilizes slice, crosscut, and circular knifes with ranges: 1/8" to 5/8" Slice Thickness, 9/32" to 3" Crosscut, 1/8" to 3" Circular. Continuous motion for uninterupted production and accept products up to 5½"in any dimension. Product is fed thru hopper into a rotating impellor into the blades. Equipped with stainless steel feed hopper, discharge chute, with lift off safety guarding start / stop buttons controls and is mounted on stainless steel base frame. Change parts required for size changes. Also has stainless steel, Inclined cleated feeder and hopper with 89" long x 24" wide neophreme product belt with 2-1/2" high lugs set on 12" centers with 59" discharge height.
OAD: 75" L x 50" W x 50" H Urschel 107" L x 54" W x 59" H Inclined Feeder
USDA approved dicer speeds vary depending on type of product used. Unit is capable of slicing 8000 Lbs/Hr of Pineapple at high speeds and 5000 Lbs/Hr of Macadamia nuts at high intermediate speeds. Unit will cut pieces as small as 1/16" X 1/8" X 1/16" and as large as 3/8" X 1/2" X 3/4". To cut different size pieces change parts are needed. Last running Mozzarella cheese in cubes. Unit is all stainless steel USDA approved. Change parts required to accommodate size range.
