Home » Form Fill Seal » Zipper Attachment
Recpro automatic, inline, re-closeable, zipper seal attachment machine capable of appling zippers up to 50 bags per minute – depending on materials and application. Unit mounts under, or behind the infeed conveyor of a form, fill, seal machine and is driven by the film unwind to ensure proper tension for the zipper application and is timed in with photo eye that reads the (eye or registration mark) for accurate placement of the zipper to the bag and is capable of appling zippers to both vertical and horizontal form, fill, seal machines and has 6" unwind spindle, double seal top and bottom heat sealing dies with temperature heat seal controllers.
OAD: 124" L x 80" W x 80" H
Zipper unwind with dancer assembly.
AMI / Zippak, Model D-25000-25, Top zipper applicator. Rated from 10 to 60 cycles per minute – with number of pouch per minute – depending on materials, application and machine configuration. Used to apply a zipper closure to most vertical form, fill and seal machines. Equipped with 18" diameter zipper spool on a 1½" core and 27" wide film roll holder, Branson 900 BCA Advanced Unltrasonic end seal with 11" Seal bar and has control panel with touch pad interface controls. Mounted on a stainless steel frame with leveling legs.
OAD: 68"L x 50"W x 82"H
Recpro, automatic, servo driven, re-closeable top zipper attachment machine designed to apply to a vertical form, fill, seal machines with number of attachments per minute – depending on materials, application and machine configeration. Mounts behind form, fill, seal machine and is driven by the machines film unwind to ensure proper tension for zipper application and timed in by photo eye for accurate placement of the zipper to the bag. Equipped with left hand zipper feed and cutting blade, ultrasonic pre-seal, cross web heat seal dies for the zipper application to top of bag which does not effect bagger speeds or seal integrity and can be used with both sophisticated barrier films, as well as monolayer films with 11" wide x 16" OD zipper unwind spindle, 34" long film rollers. Control panel has PLC controller with touch pad controls and panelview. Mounted on base frame with casters and leveling legs.
OAD: 75" L x 70" W x 78" H
