Form and Fill Towelette is a machine which uses one or two rolls of film to create pouches. Form and fill towelette machine inserts towelettes or small pads of material into the pouch and can insert drops of liquid into the pouch along with the towelette. As an example of what form and fill towelette machines are capable of, picture moist towelette wipes at restaurants
Circle, Model V6B2, vertical, 2-up, form fill and seal machine. Rated from 10 to 60 cycles per minute – depending on materials and application. Pouch size range: 2¼" to Unlimited in Length; 1" to 7" in Width. Equipped with film slitter, registration, tension assist, film assist pull wheels, 2-up towelette inserter, liquid filling system, tear notch punch, (4) lobe horizontal cross seal arbors, side sealers, cross cut knife. Control panel with visual display. Film specifications: up to 16" in Width; up to 14" in diameter; 3" core. Mounted on height adjustable base frame.
OAD: 70"L x 60"W x 85"H
Towelette pouch packager currently set for a 3 up 16 panel towelette. The towelette is based on 3 – 8" webs, fed thru a 4 fold plow, 9-1/2" cut-off & then fed thru double fold head for insertion into pouch. Final towelette is 2-1/4 x 2-1/2". Packager uses single roll stand for 8" max webs, registered, split & folded thru vertical heat seal section.Now set up for 3 x 3 1/2" wide x 3 1/2" long pouches. Equipped with 5 cc filamatic liquid dosage pumps for moistened towelette applications, UV Light box for towellette material steriliziation & 10" wide x 10′ long discharge conveyor. The complete towellete fan & cross folding plus package film roll stand is unitized on the towellete head.
OPTION: Emboss code in side seal, tear notch
Bartelt, Model IM4-10, compact, horizontal, mechanical driven, intermittent motion, form, fill, seal, machine, rated from 20 to 60 pouches per minute – depending on materials and application. Maximum film roll width of 12" and maximum pouch width of 2.75". Film passes through forming head into a side and bottom heat sealer by 6" roll puller. Separated pouch is opened with a blower assembly and travels on a clip feed chain, with 10 stations set on 4" centers. Towelette filling head utilizes (2) Hibar filling pumps with dual nozzles for 2 up fill. Rocker assembly closes top of pouch before going into final seal area. Control panel has temperature on / off switches for guard override, heaters and vacuum, also toggle switch for run / jog and eye reset button, drive start / stop and E-stop. Mounted on heavy duty base frame.
Coder and tear notch assemblies available at an additional cost.
OAD: 132"L x 48" W x 77" H
Bossar Model B1400, compact, 2-up, double fold horizontal, continuous, intermittent motion, form, fill, seal towelette machine rated from 40 to 120 pouches per minute – depending on materials and application. Pouch size range: 50mm to 70mm in Width; 70mm to 170mm in Length and product doses between 20cc and 60cc with proper change parts. Equipped with dual roll film unwinds, film tension rollers, pouch former, pouch feed conveyor, top, bottom, side seal with cut-off stations, no pouch detection, duck bill style pouch openers, towelette feeder, liquid fill station and pouch pick-off discharge. Control panel with (4) Omiron heat controllers, on / off, heating, vacuum, film feed, towellete control switches with e-stop.
OAD: 108" L x 59" W x 69" H Bossar Machine 86" L x 36" W x 62" H Dual Film Feed
Circle Model V18VD4C, Vertical, 6-up, servo driven form fill and seal rated 10 to 60 cycles per minute – with number of product – depending on materials and application. Pouch size range: 2-1/8" to Unlimited in Length; 1-1/2" to 18" in Width. Equipped with powered film unwind, film slitter, registration, tension assist, film assist pull wheels, liquid filling system with (6) Filamatic pistons, (3) lobe horizontal cross seal arbors, side sealers, cross cut knife. Film specifications: up to 36" in Width; up to 14" in diameter; on 3" core. Control panel has relay logic controller and has swing arm controls with start, stop, jog, run, main safety with temperture controllers and e-stop. Mounted on height adjustable legged frame.
Videojet Dataflex inkjet coders available at added cost
OAD: 110" L x 60" W x 100" H
